D7145 spark electric discharge machine cnc edm spark erosion machine die sinking machine
- Category: >>>
- Supplier: Tengzhou Hoyong Trading Co. Ltd.
Share on (1601025938752):
Product Overview
Description
Main Features
1) Japan SANYO DC servo motor in Z axis.
2) X,Y axes adopts precise ball screw.
3) Professional database system.
4) High speed 400mm3/min.
5) Surface roughness Ra0.8.
6) Taiwan control system.
7) Germany guideway.PVC coating for wear resistance.
8) SIEMENS,Germany AC contactor.
9) OMRON relay.
10) Japan high frequency power tube.
11) Harbin bearings.P5 grade.
12) Castings,HT250 resin sand.
Electroerosion JS EDM Introduction
The electrical discharge machining are used with impulse electric cabinet.Z axis is driven by Japan SANYO DC servo motor,with Z
axis numerical control feature.
X,Y axes adopt precise ball screw,and precision optical grating digital display shows the coordinate which make coordinates have
high positioning accuracy.
Electric cabinet of electrical discharge machining adopts the most advanced industry-specific control board,strong function,good
stability,simple operation.
As long as input a few parameters,such as Z axis depth,it will select a set of suitable date from the expert database system that
matches the processing,and process from the rough processing to finish once automatically.
1) Japan SANYO DC servo motor in Z axis.
2) X,Y axes adopts precise ball screw.
3) Professional database system.
4) High speed 400mm3/min.
5) Surface roughness Ra0.8.
6) Taiwan control system.
7) Germany guideway.PVC coating for wear resistance.
8) SIEMENS,Germany AC contactor.
9) OMRON relay.
10) Japan high frequency power tube.
11) Harbin bearings.P5 grade.
12) Castings,HT250 resin sand.
Electroerosion JS EDM Introduction
The electrical discharge machining are used with impulse electric cabinet.Z axis is driven by Japan SANYO DC servo motor,with Z
axis numerical control feature.
X,Y axes adopt precise ball screw,and precision optical grating digital display shows the coordinate which make coordinates have
high positioning accuracy.
Electric cabinet of electrical discharge machining adopts the most advanced industry-specific control board,strong function,good
stability,simple operation.
As long as input a few parameters,such as Z axis depth,it will select a set of suitable date from the expert database system that
matches the processing,and process from the rough processing to finish once automatically.
Item | D7132 | D7140 | D7145 | D7150 | D7160 |
Worktable size(mm) | 500x200 | 650x400 | 720x450 | 800x500 | 1000x600 |
Worktank size(mm) | 1030x560 x320 | 1050x630 x410 | 1400x710 x410 | 1450x780 x500 | 1680x850 x580 |
X axis trave(mm)l | 320 | 400 | 450 | 500 | 600 |
Y axis travel(mm) | 250 | 300 | 350 | 400 | 450 |
Z axis travel(mm) | 240+240 | 250+250 | 250+250 | 250+300 | 250+350 |
Distance between electrode and worktable(mm) | 550 | 650 | 680 | 700 | 800 |
Max. workpiece weight(kg) | 550 | 750 | 800 | 800 | 1000 |
Max. Electrode weight(kg) | 60 | 70 | 80 | 100 | 150 |
Machine weight(kg) | 1200 | 1800 | 2000 | 2200 | 3000 |
Machine size(mm) | 1100x1400 x2120 | 1100x1200x2040 | 1500x1500x2250 | 1600x1500x2300 | 1700x1600x2400 |
