Roller glass coating machine
US $10000-$13000
Hot Sale Electric glass lifter sucker truck, automatic glazing robot, large size glass install and move equipment
- Category: >>>
- Supplier: Qingdao Dinganda Glass Technology Co. Ltd.
Share on (1601026196345):
Product Overview
Description
Products Description
Fully automatic electric sucker truck
This machine is light and flexible in operation, and it is a new type of glass handling machinery with energy saving, high efficiency and environmental protection.
It is widely used in curtain wall glass installation, stone slab and plates transportation.
In factories, warehouses, logistics centers and many other places, the handling of glass panels is safe and efficient, and fully reflects its excellent flexibility, stability and environmental protection performance.
One person can operate, saving labor costs and improving engineering efficiency
Details Images
Model No. | RSY-Y800Q-3 | ||
Maximum operating height | 4.5m | ||
Maximum working weight | 800KG | ||
Driving method | 24V motor front drive | 2.2KW | |
Climbing ability | 15% | 15% | |
Maximum driving speed | 5km/h | 5km/h | |
Suction cup parameter | 500mm diameter | 6 Pcs | |
Vacuum pump | 24V vacuum pump | 2 Pcs | |
Vacuum warning prompt | Digital display&Mechanical | Automatic vacuum holding, buzzer alarm, mechanical pressure gauge | |
Forearm telescopic distance | Hydraulic pressure | 2*550mm | |
Tilting control | 0-130 degrees | 0-135 degrees | |
Horizontal movement | ±50mm | ||
Lateral torsion angle | ±90mm | ||
Rotation control | 360 degrees | ||
Battery | DC12v 150AH | 2 pcs | |
Charging time | 4-8h | ||
Total weight | 1960kg | ||
Size | 3.2m*1.2m*1.4m (L*W*H) | ||
Packing box size | 3.2m*1.3m*1.9m (L*W*H) | ||
