Rope reinforced fiber high strength rope raw material PBO fiber
PBO fiber is regarded as the super fiber in 21st Century due to its unique molecular structure, extremely high strength, excellent modulus, outstanding heat resistance and flame resistance.
the PBO can also be used for making high-strength ropes, lifting ropes, cables, high pressure vessel winding,sewing threads, machine protective cover, heat shield,thermal shields. Safety gloves.
Features:
Excellent flame resistance
High strength and modulus
Chemical resistance
Anti-fatigue
MAIN APPLICATION
AEROSPACE
SPORTS EQUIPMENT
FILTER MATERIAL
FIREMEN UNIFORM
Unit | Series | |||
| / | XCHS-11 | XCHS-12 | XCHM |
appearance |
| Light yellow | Light yellow | Dark yellow |
density | G/cm3 | 1.54 | 1.54 | 1.56 |
Linear density | dtex | 220 278 555 | 220 278 555 | 216 273 545 |
1110 1670 | 1110 1670 | 1090 1640 | ||
Moisture regain | % | ≤ 4 | ≤ 4 | ≤ 2 |
Oil content | % | 0-2 | 0-2 | 0-2 |
Tensile strength | cN/Dtex | ≥ 36 | ≥30 | ≥36 |
Gpa | ≥ 5.6 | ≥4.7 | ≥5.6 | |
Tensile modulus | cN/Dtex | ≥1150 | ≥850 | ≥1560 |
Gpa | ≥180 | ≥130 | ≥240 | |
Elongation at break | % | 3.5 | 3.5 | 2.5 |
Decomposition temperature | °C | 650 | 650 | 650 |
LOI | % | 68 | 68 | 68 |
application:
company introduction:
We are specialized in manufacturing aramid yarn,sewing thread, fabric series like knitting, woven fabrics in rolls and aramid felt with nonwoven since 2009. according to the different requirements of customers. Produce all kinds of special specification Aramid products to meet customers’ needs/.
