XCMG XD103 road compactor 10 ton double drum pavement road roller with price
- Category: >>>
- Supplier: Xuzhou Construction Machinery Group Import & Export Co. Ltd.
Share on (1601029961828):
Product Overview
Description
10 ton XCMG double drum pavement roller XD103.
Pavement roller XD103 which is independent researched and developed by XCMG road machinery business division based on years of
experience in compaction machinery research and development.
XCMG paverment roller XD103 is designed for the compaction of asphalt pavement, asphalt layer of different materials and different
thickness, especially suitable for roads, parking lots, airports and other large engineering projects, can also be used for
compaction of roadbed and sub-base material, wide application scope.
experience in compaction machinery research and development.
XCMG paverment roller XD103 is designed for the compaction of asphalt pavement, asphalt layer of different materials and different
thickness, especially suitable for roads, parking lots, airports and other large engineering projects, can also be used for
compaction of roadbed and sub-base material, wide application scope.
Performance Characteristics:
1.The console can rotate about 35 degrees, improving the driving comfort.
2.The steering wheel can adjust angle according to the need of the driver.
3.Control handle, display, etc. are arranged on the right side to broaden the front view.
4.Speed frequency management system guides the user to compaction operation.
5.Guiding the user to improve operation efficiency.
6.The vibration drum realizes the center of four-in-one combination.
7.Preventing the over-compaction and less-compaction.
2.The steering wheel can adjust angle according to the need of the driver.
3.Control handle, display, etc. are arranged on the right side to broaden the front view.
4.Speed frequency management system guides the user to compaction operation.
5.Guiding the user to improve operation efficiency.
6.The vibration drum realizes the center of four-in-one combination.
7.Preventing the over-compaction and less-compaction.
Parameter | Unit | XD103 |
Working weight | kg | 10000 |
Front wheel distribution weight | kg | 5000 |
Rear wheel distribution weight | kg | 5000 |
Static linear load | N/cm | 280/280 |
Nominal amplitude | mm | 0.35/0.6 |
Vibration frequency | Hz | 58/48 |
Exciting force (high frequency/low frequency) | kN | 90/110 |
Vibration wheel size | mm | 1150*1750 |
Vibration wheel size | km/h | 0~6/0~12 |
Theoretical gradeability | % | 35 |
Minimum turning radius (in/out) | mm | 4070/5820 |
Swing angle | ° | ±10 |
Steering angle | ° | ±38 |
Rated power | 74.9kW | 74.9 |
Rated speed | r/min | 2300 |
