6inch 2600nits 4K HDMI Touch Screen Broadcast Monitor
- Category: >>>
- Supplier: TL Technology (Shenzhen) Co. Ltd.
Share on (1601030436738):
Product Overview
Description
Product Description
6inch 2600nits 4K HDMI Touch Screen Broadcast Monitor
Model# M6-2600
Advanced Features
*Support User 3D LUT Upload *Anamorphic Mode (1.25x, 1.33x, 1.5x, 2.0x, 2.0x mag)
*Support Touch Menu *Image Flip (H, V, H/V)
*Support HDR Monitoring (HLG 2020, HLG 709, HLG P3) *Auto Mirror
*All Waves *Zoom (100%~300%)
*Parade (RGB, YUV, Y) *Image Freeze
*Vector *Nine Grid
*RGB Histogram *Pixel to Pixel
*Histogram *Check Field (red, green, blue, gray)
*Peaking Focus (red, green, blue, white, yellow five peaking colors optional; 1~10 peaking level adjustable) *Center Marker
*Audio Meter *Safety Marker (70%, 80%, 90%, 16:9, 16:10, 4:3, 5:4, 1.85:1, 2.35:1)
*Zebra Exposure (1%~100% adjustable) *Ratio Marker (16:9, 16:10, 4:3, 1.85:1, 2.35:1)
*False Color *Marker Color (red, green, blue, white, black, yellow)
*Scan Mode (over scan, under scan) *Color Temperature Adjustment
Specifications
*Support User 3D LUT Upload *Anamorphic Mode (1.25x, 1.33x, 1.5x, 2.0x, 2.0x mag)
*Support Touch Menu *Image Flip (H, V, H/V)
*Support HDR Monitoring (HLG 2020, HLG 709, HLG P3) *Auto Mirror
*All Waves *Zoom (100%~300%)
*Parade (RGB, YUV, Y) *Image Freeze
*Vector *Nine Grid
*RGB Histogram *Pixel to Pixel
*Histogram *Check Field (red, green, blue, gray)
*Peaking Focus (red, green, blue, white, yellow five peaking colors optional; 1~10 peaking level adjustable) *Center Marker
*Audio Meter *Safety Marker (70%, 80%, 90%, 16:9, 16:10, 4:3, 5:4, 1.85:1, 2.35:1)
*Zebra Exposure (1%~100% adjustable) *Ratio Marker (16:9, 16:10, 4:3, 1.85:1, 2.35:1)
*False Color *Marker Color (red, green, blue, white, black, yellow)
*Scan Mode (over scan, under scan) *Color Temperature Adjustment
Specifications
Screen size 6" IPS
Display Colors 16.7M (8 bit)
Resolution 1920x1080 pixels
Dot pitch 0.069(L) x 0.069(W) (mm)
Aspect Ratio 16:9
Brightness 2600cd/m2
Contrast 1000:1
Backlight LED
Response Time Ton+Toff=35ms
Viewing Angle 80°/80°(L/R) 80°/80°(U/D)
Input 3G-SDI, HDMI
Output 3G-SDI, HDMI
Power Out DC OUT 8.4V, Barrel (5.5mm outer, 2.1mm inner; Power DSLR or mirrorless camera)
Audio 3.5mm Stereo Headphone
SDI Input Support Format 720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)
2048x1080i (60/59.94/50)
2048x1080p (60/59.94/50/30/29.97/25/24/23.98)
SDI Output Support Format 720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)
HDMI Input/ Output Support Format 480i/576i/480p/576p
720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)
3840×2160p (30/29.97/25/24/23.98)
4096×2160p (30/29.97/25/24/23.98)
Power Consumption ≤16W
Input Voltage DC7 ～24V
Power Connector DC
Battery Plate F970 Battery Plate
Operating Temperature -20℃ ～ 50℃
Storage Temperature -30℃ ～ 60℃
Install Way 1/4"-20 Thread Point ( Right, Bottom)
Unit Size 162Lx93.2Hx29D (mm)
Unit Weight 300g
Standard Accessories
Mini/ Micro HDMI to HDMI Cable
Tilt Arm
Operation Manual
Specification
Size | 6 inches |
Physical resolution | 1920*1080 |
Display ratio | 16：9 |
Brightness | 2600cd/m2 |
Contrast ratio | 1000:1 |
