Product Overview

Description



Product Overview


5 Port 1000M Ethernet switch
5* 10/100/1000Mbps auto-sensing RJ45 ports, auto MDI/MDIX.
Full duplex and half duplex, preventing frame loss from port blocking.
Auto-detecting of parallel / cross line. Simplify the network structure and maintenance.
Support connection with IP Cameras and wireless AP.
Plug and play, no need more configuration.
Low power consumption design. Low power consumption design. Energy-saving and green. Max total power consumption < 6W.
1 year warranty.




Products Description




PRODUCT SPECIFICATIONS


Model
EW-S1605CG
Product Name
5-Port 10/100/1000M Network Switch
Interface
5* 10/100/1000Mbps auto-sensing RJ45 ports(Auto MDI/MDIX)
Feature
Gigabit non-blocking transmission, keeps network fluent.
Support MAC self learning and updating
Network Protocol
IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;
IEEE802.3u 100Base-TX;
IEEE802.3ab 1000Base-T;
IEEE802.3x.
Twisted Pair Transmission
10BASE-T: Cat5 UTP (≤100 meter)
100BASE-TX: Cat5 or later UTP (≤100 meter)
1000BASE-T: Cat5 or later UTP (≤100 meter)
Forwarding Mode
Store-and-Forward
Forwarding Rate
7.44Mpps
Back-bound Bandwidth
10Gbps
Buffer Memory
1M
MAC Address Table
2K
Standard Protocol
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE802.3ab, IEEE802.3z
LED Indicator
Power indicator: PWR (Green);
Network indicator: 1-5(Link/Act)/ (Green)
Power Consumption
Standby State: 0.7W. Max power consumption ＜ 2W
Power Input
AC:100～240V;50~60Hz
Power Output
5V/1A (External power adaptor)
120W /48VDC
Dimension
100mm*70mm*27mm（L*W*H）
Standby:<1W; Full load:<120W
Dimension
83*52*22mm（L*W*H）
Power Supply
No, optional 48V/60W or 48V/120W industrial power supply
Operation TEMP / Humidity
-40~+85°C;5%~90% RH Non condensing
Storage TEMP / Humidity
-40~+125°C;5%~95% RH Non condensing
Dimension (L*W*H)
98*120*36mm
