FY TOPCon HJT 690W Bifacial Solar Panels Commercial Grade Double Glass PERC Solar Panel
- Category: >>>
- Supplier: Jiaxing Botao Trading Co. Ltd.Jiaxing Ltd.
Share on (1601033267415):
Product Overview
Description
SPECIFITIONS | ||||||||||
module | 700w | 705w | 710w | 715w | 720w | |||||
STC | ||||||||||
maximum power | 700w | 705w | 710w | 715w | 720w | |||||
open circuit current | 50.13v | 50.29v | 50.44v | 50.59v | 50.74v | |||||
short circuit current | 17.43v | 17.49v | 17.55v | 17.61v | 17.67v | |||||
voltage at maximum power | 42.10v | 42.25v | 42.39v | 42.54v | 42.68v | |||||
urrent maximum power | 16.63a | 16.69a | 16.75a | 16.81a | 16.87a | |||||
module efficiency | 22.53% | 22.70% | 22.86% | 23.02% | 23.18% | |||||
maximum system voltage | 1500dc | |||||||||
maximum series fuse rating | 30a | |||||||||
power tolerance | 0/+5w | |||||||||
no of cells | 132cells | |||||||||
dimensions | 2384x1303x35mm | |||||||||
weight | 38.7kgs | |||||||||
junction box | ip68 | |||||||||
