Flygoo 0 10ppm Fixed Portable Handheld Dissolved Ozone Meter With Signal Output
- Category: >>>
- Supplier: Flygoo Eco-Technologies (Guangzhou) Co. Ltd.
Share on (1601034353345):
Product Overview
Description
Product Description
Flygoo 0-10ppm Fixed Online Ozone Gas Detector Ozone Meter with Signal Output for Air
Flygoo YT-95H series Ozone Gas Detector is equipped with original imported ozone sensors that provide accurate detection of the gas. The Ozone gas detector(with alarm light) is a kind of monitoring gas concentration in different kinds of situations or pipelines 24h continuously wall mounted type gas detector. Using world first brand sensors, and advanced micro-process technology,with data display and high/low alarm, fast response, high precision and good stability.It comes standard with a three-wire system 4-20mA analog output, relay output, and RS485 output (optional). Explosion proof, suitable for different kinds of situations.The Ozone Gas Detector is compatible with all kinds of controlled alarms, PLC, DCS, and other control systems, making it easy to integrate with existing equipment.
Specification
Gas Detected | Ozone (O3) |
Detection Principle | Electrochemistry |
Install Method | Wall-mounted, piping type, flow-type(according to the detected environment) |
Measure Range | 0-1ppm, 0-5ppm, 0-10ppm, 0-20ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0- 1000ppm (range is optional) |
Resolution | 0.001ppm, 0.01ppm, 0.1ppm, 1ppm |
Precision | 5%FS |
Output signal | 4-20MA; 0-5V RS485; RS232; Relay (optional) |
Response Time | ≤10S |
Recovery Time | ≤10S |
Repeatability | ≤±1% |
Linearity error | ≤±1% |
Zero shift | ≤±1%（F.S/year |
Connection mode | G1/2 external thread explosion-proof flexible pipe |
Temperature | -20℃～50℃ |
Explosion-Proof | Ex dⅡCT6 |
Power | 12-36V DC |
Dimensions | 180×150×90mm |
Display | High light nixie tube display |
Thread Size | M45*2mm |
Humidity | 0-95%RH |
Degree of protection | IP65 |
Operating time | 24h |
Weight | ≤1.6kg |
Feature
1.Employing original imported ozone sensor.
2.Standard equipped with three-wire system 4-20mA analog output; relay output; RS485 output (optional)
3.Unique infrared ray control function, which can non-contacted Control the device.
4.Being compatible with all kinds of controlled alarms, PLC, DCS and other control system, can be remote monitored.
5.Explosion-proof design, fast, reliable and stable. Explosion-proof grade: Ex dⅡCT6
6.With self-calibration function, and three standard keys will be used to realize on-site maintenance.
2.Standard equipped with three-wire system 4-20mA analog output; relay output; RS485 output (optional)
3.Unique infrared ray control function, which can non-contacted Control the device.
4.Being compatible with all kinds of controlled alarms, PLC, DCS and other control system, can be remote monitored.
5.Explosion-proof design, fast, reliable and stable. Explosion-proof grade: Ex dⅡCT6
6.With self-calibration function, and three standard keys will be used to realize on-site maintenance.
7.Can output one or two on-off signals, can drive ventilator or solenoid valve and other external devices.
8.Working Voltage:12-36V DC
9.Case:die-cast aluminum + stainless steel (alarm light)
Application
1.Petrochemical industry, industrial manufacture, smelting, electricity, coal mining, tunneling, environment monitoring, waste water treatment.
2.Bio-pharmaceutical plant, green household, livestock breeding, green house cultivating, warehouse logistics, brewing and fermentation, agricultural production.
3.Fire control, fuel gas, building, municipal enterprise, school lab, research centre.
2.Bio-pharmaceutical plant, green household, livestock breeding, green house cultivating, warehouse logistics, brewing and fermentation, agricultural production.
3.Fire control, fuel gas, building, municipal enterprise, school lab, research centre.
