MD680 TYT MD 680 10W DMR digital walkie talkie with IP67
- Category: >>>
- Supplier: Quanzhou Anytalk Telecom Co. Limited
Share on (1601034705800):
Product Overview
Description
ANYTALK Walkie Talkie, the legitimate use of green and healthy.
Handheld radio the Green public radio, can completely relieve your worries!
TYT MD-680 10W DMR digital two way radio
IP67 waterproof
2200mAh battery capacity
10Watt output power
Digital and analog combined
Text message in digital mode
Busy channel lock
Wide/narrow bandwidth selective
Private/group/all call function
Programming side-key
Battery save function
TOT
High/low power selective
End-tone elimination
| Item number | MD-680 |
| General | |
| Frequency Range | 400-470MHz |
| More frequency available | 450-520/136-174/220-260/245-245.9875MHZ |
| More frequency available | 256 |
| Working voltage | 7.2v |
| Working temperature | -30℃~+60℃ |
| Storage temperature | -40℃~+85℃ |
| Continuous working time | Analog:15hours Digital:25hours |
| Battery capacity | 2200Mah |
| Transmitter | |
| Frequency Range | 400-470MHz |
| Channel spacing | 12.5KHZ |
| Frequency stability | +/-1.5ppm |
| TX power | Low:1W High:10W |
| FM noise | -40dB 12.5KHZ |
| Spurious emission | <60dB m 1GHZ,> -30dB m 1G |
| Adjacent channel selectivity | -60dB 12.5KHZ |
| FM modulation mode | 12.5KHZ:11 F 0 F 3 E |
| 4FSK digital modulation mode | 12.5KHZ(data only):7K60FX 12.5KHZ(data+voice):7K60FX |
| Modulation limit | 2.5KHZ12.5KHZ |
| Audio response | +1dB~-3dB |
| Rated audio distortion | ≤3% |
| Digital protocol | ETSITS102361-1,-2,-3 |
| Vocoder type | AMBE+2TM |
| Receiver | |
| Frequency Range | 400-470MHz |
| Channel spacing | 12.5KHZ |
| Frequency stability | +/-1.0ppm |
| Analog sensibility | 0.35uV/-116dBm(20dB SINAD) 0.22 uV/-120dBm(Typical) |
| Digital sensibility | 0.3 uV/-117.4dBm(BER 5%) 0.7 uV/-110dBm(BER 1%) |
| Spurious response | TIA603C: 65dB ETSI: 65dB |
| Adjacent channel selectivity | TIA603C: 60dB @ 12.5KHZ ETSI: 60dB @ 12.5KHZ |
| Spurious response suppression | TIA603C: 70dB ETSI: 70dB |
| Receiving spurious emissions | <-57dBm@1GHZ,> -47dBm |
| Blocking | 84dB |
| Rated audio power | 1w |
| Audio response | +1dB~-3dB |
| Rated audio distortion | ≤3% |
Using rechargeable walkie-talkie for the first time, please charge for 16 hours.
Turn off your computer before removing the battery.
Please do not use hand to pick up the antenna, hold the antenna will affect the effective wireless intercom call range.
Use the walkie-talkie, you should keep it vertical distance of 5.0 to 7.0 cm, and keep your face.
Please try to use while driving handsfree speaker and the closing words.
Keep your intercom televisions, computer monitors and other screen to maintain a distance greater than 10cm, to avoid being magnetized.
The interphone Do things together with other metal-containing storage.
Walkie-talkies may interfere with some hearing aids, with your hearing aid manufacturer to discuss alternatives.
Try to place in the medical walkie-talkie off, so as not to affect the use of medical equipment.
Do not use in airports and on aircraft. If so, prohibited driving the car to the side of the road and then.
In potentially explosive areas must remain shut down, unless it is dedicated intercom dangerous areas (for example, Factory Mutual, CAS, or UL certified).
