$6.50-7.00
10 30w/m Power Optional Twin Conductor Warm Infrared Insulated Alloy Heating Wire Cable Used for Underfloor Heating
- Category: >>>
- Supplier: Hefei Minco Heating Cable Co. Ltd.Hefei Ltd.
Share on (1601035963707):
Product Overview
Description
Products Description
Specifications:
- Cable Construction:Twin conductor- Operating voltage: 200~240V, 50/60Hz
- Power: 10w/m, 15w/m, 20w/m, 30w/m (3 types)
- Cable diameter: 3.6mm±1
- Min. bending radius: 25mm
- Conductor insulation: Fluoropolymer/XLPE/Rubber
- Outer insulation: PVC
Notice:
1. Do not cut for use
2. Do not cross or overlap
2. Do not cross or overlap
Advantages:
1. excellent thermal shock resistance.
2. flame retardant, no fire hazards.
3. longer service life.
2. flame retardant, no fire hazards.
3. longer service life.
Details Images
Features
1,Heating core:
Using multi-strand alloy wire twisted, strong stability, flexible and easy construction.
2,Insulation:
The use of flame-retardant silicone rubber insulation, the maximum high temperature up to 260 degrees. Silicone rubber has good anti-aging, thermal conductivity, weatherability, corrosion resistance and has a high resistivity.
3,Double shield:
Copper mesh plus aluminum foil double shield with leakage protection, grounded after the safety and no electromagnetic radiation concerns.
4,Hot and cold wire connector:
Factory cooling hot wire joints multi-layer protection, double injection molding process to ensure stable joints, compression and impact resistance, with a very strong waterproof and leakage protection!
5,Outer jacket:
Using high temperature of 105 ℃ flame retardant green PVC.
6,Cold line:
Long 2m, the use of multi-strand pure copper cord, good flexibility, easy installation and wiring.
Using multi-strand alloy wire twisted, strong stability, flexible and easy construction.
2,Insulation:
The use of flame-retardant silicone rubber insulation, the maximum high temperature up to 260 degrees. Silicone rubber has good anti-aging, thermal conductivity, weatherability, corrosion resistance and has a high resistivity.
3,Double shield:
Copper mesh plus aluminum foil double shield with leakage protection, grounded after the safety and no electromagnetic radiation concerns.
4,Hot and cold wire connector:
Factory cooling hot wire joints multi-layer protection, double injection molding process to ensure stable joints, compression and impact resistance, with a very strong waterproof and leakage protection!
5,Outer jacket:
Using high temperature of 105 ℃ flame retardant green PVC.
6,Cold line:
Long 2m, the use of multi-strand pure copper cord, good flexibility, easy installation and wiring.
