Name | |
Nominal voltage | 12V |
Nominal capacity | 200ah |
Model | DL-12200 |
Dimension | 521*238*218mm or customized |
End of charge voltage | 14.6V |
End of charge current | 200mA |
End of discharge voltage | 9.2V |
Charge method | CC/CV(constant current/constant voltage) |
Max continuous charge current | 100A |
Max continuous discharge current | 200A |
Max pulse discharge current | 400/10S |
Net weight | 22kg |
Case material | metal case or stainless steel case |
Warranty | 5 years |
BMS protect | Overcharge,Balance, Over-discharge,Over-current, Short-circuit etc |
Terminal Type | M8 or anderson or another bolt screw |
Lifecycle | over 6000times |
Charge temperature | 0~45℃ |
Discharge temperature | -20~60℃ |
Storage temperature | -10~45℃ |
