China supplier magnetic iron separator for conveyor belt
- Category: >>>
- Supplier: Qijin Magnet Co. Ltd.
Share on (1601040165078):
Product Overview
Description
Company Information
Since founded in Year 2002 , our company devoted to manufacturing high-end permanent magnetic equipment and magnets. Our company covers an area of 15,000sqm with modernized workshops and we have successfully designed and built several magnetic separation lines in more than ten countries such as America, Thailand, Mexico, the Philippines, Indonesia, Europe etc. Our magnetic separators have been exported to more than 70 countries and commonly applied in raw material recovery, metal recycling industry, waste industry, refuse processing and mining industry to select magnetic materials out of material stream or to purify material. Our major products are eddy current separator, over band magnetic separator, magnetic drum and suspended magnets. All these equipment can be designed and manufactured in accordance with the specific requirements of our customers.
Product Description
QJRCY magnetic separator for conveyor belt (suspended overband magnetic separator) offer superior strength and reliability and are designed for separation of ferrous metal from kinds of belt conveyed products. The advanced design and construction make suspension overband magnet ideal for use in recycling, fire shredding, wood chip, mining and demolition applications.
Features:
1. Suspended Magnetic Separator for Conveyor Belt provide powerful deep reaching magnetic circuit design to penetrate heavy product burdens.
2. Strong magnetic field intensity, high gradient and strong attractive force.
3. The unique stainless steel plate-armored belt can protect the belt from damage by sharp ferromagnetism material.
4. Non-excitation and self-cleaning will bring us energy saving and convenience in operation.
5. The belt of Overband Magnetic separator has self-adjustment function and the special sealed bearing block ensure the stable working in harsh environment.
6. Safe specification meets the international standard. is mainly applicable to the separation of non-ferrous metals such as copper and aluminum from industrial
wastes and household wastes for more precise sorting.
Specification
| Model | Applicable Conveyor Width | Applicable Conveyor Speed | Material Burden Depth | Rated Suspended Height | Motor Power |
QJRCY-L-50 | 500mm | ≤4.5m/s | ≤100 | 180mm | 1.5kw |
QJRCY-L-65 | 650mm | ≤150 | 200mm | 1.5kw | |
QJRCY-L-80 | 800mm | ≤200 | 250mm | 2.2kw | |
QJRCY-L-100 | 1000mm | ≤250 | 300mm | 3.0kw | |
QJRCY-L-120 | 1200mm | ≤300 | 350mm | 4.0kw | |
QJRCY-L-140 | 1400mm | ≤350 | 350/400mm | 4.0kw | |
QJRCY-L-160 | 1600mm | ≤400 | 350/400/450mm | 5.5kw | |
Optional: T series applicable for the high materials thickness and high material density application T1 - 700Gauss | T2 - 900Gauss | |||||
Related Products
Packaging & Shipping
FAQ
1.How is the quality of your products?(mining equipment/machine
Our products are manufactured strictly according to national and international standard, and we will take a test on every equipement before delivery.
2.Guaranteed:
All of our products are guaranteed for one year. If products quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.
3.How about price?
For the complete same machine, we can promise our quality is the best when the price same as other competitors, and our price can be lowest when the quality at standard level.
4.Service and Payment Terms?
We can accept T/T and L/C; 30% deposit, 70% balance before delivery, which is international trade practice; Finished product pictures will provide to customers before delivery.
