  • YZA 026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches
YZA 026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches
YZA-026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches
YZA-026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches
YZA-026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches
YZA-026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches
YZA-026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches
YZA-026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches

YZA 026 3*6*3.3/3.5/3.8/4.3/5MM side light push button with pillars SMD key switches

Share on (1601040468915):


Price:

Quantity:


Product Overview

Description



Product Description




Specification


item
value
Whether the smart
NO
Place of Origin
China
Guangdong
Brand Name
YZ
Model Number
YZA-026
Max. Current
0.5A
Max. Voltage
12V
LED
NO
IP level
IP00
Product name
Tact Switch
Product number
YZA-026
Size
3*6*3.3/3.5/3.8/4.3/5MM
Rated electrical load
DC12V 0.5A
Contact resistance
≤100Ω
Insertion force
160gf
Working temperature
-25℃~+70℃
Life
50000 Cycles
