Rockchip RK3288 Android Motherboard RK3399 RK3568 Android Projector Motherboard
- Category: >>>
- Supplier: Suzhou Dewo Smart System Co. Ltd.
Share on (1601040630746):
Product Overview
Description
Product Description
Specification
Processor | Processor: RK3288 CPU: 4 core Cortex A17 architecture, the highest frequency is 2GHz |
GPU | ARM MALI T764) |
Memory/storage | Standard 2G (4G optional)/ EMMC standard 16G (8G/32G/64G optional) |
Built in ROM | 32K EEPROM |
LVDS output | 1* single/dual channel, can directly drive 1920x1080 LCD screen |
EDP output | Maximum drive 4KX2K resolution eDP interface LCD screen |
HDMI output | 1*, support 1080P@60Hz, 4kx2k@60Hz output |
MIPI output | Single/dual channel MIPI output |
Audio and video output | Support left and right channel output, built in dual 8R/5W power amplifier |
Headset | Support one headphone jack |
USB interface | 1* USB2.0(support OTG/HOST switch), 7* USB2.0 HOST, total 8* USB |
Serial port | 4* RS232, 2* RS485, 1* TTL, 1* DEBUG, total 8 serial port |
MIPI camera | Dual channel support dual camera 30pin FPC interface, support 1300w Camera |
TF card | Support TF card |
WIFI, Bluetooth | Built in WIFI, BT4.0 (optional) WIFI module, support WIFI hotspot sharing during 4G communication |
3G/4G | Built in WCDMA, EVDO, 4G full Netcom, support 4G routing |
Ethernet | 5*, adaptive 10M/100M Ethernet |
System Upgrade | Support local USB upgrade |
