Cooling Heating Split Wall Air Conditioners R32 24000Btu 220V 50Hz A Efficiency Power Save Air Conditioners Inverter by TCL
- Category: >>>
- Supplier: Dongguan City Changping Saint J. Electrical Firm
Share on (1601040649476):
Product Overview
Description
Product Description
Product Parameter
| TAC-09CHSDT | TAC-12CHSDT | TAC-18CHSD | TAC-24CHSD | |||
| Type | heating pump | heating pump | heating pump | heating pump | ||
| Control type | remote controller | remote controller | remote controller | remote controller | ||
| Power supply | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | 220-240V~/50Hz/1P | ||
| Voltage Range | V | 165~265 | 165~265 | 165~265 | 165~265 | |
| Declared cooling capacity | W | 2600(940~3300) | 3400(1000~3770) | 5100(1250-5910) | 6810(1830~7800) | |
| Declared cooling capacity | W | 2610(940~3360) | 3420(1000~3810) | 5100(1250-6070) | 6870(1850~7900) | |
| Pdesignc | W | 2600 | 3400 | 5100 | 6800 | |
| SEER declared | W/W | 6.1 | 6.1 | 6.1 | 6.1 | |
| Energy Class | A++ | A++ | A++ | A++ | ||
| Pdesignh Average | W | 2000 | 2100 | 3800 | 4800 | |
| SCOP Average declared | W/W | 4 | 4 | 4 | 4 | |
| Energy Class(Average) | A+ | A+ | A+ | A+ | ||
| Declare capacity(-10℃) | W | 1900 | 2000 | 3600 | 4500 | |
| Back up heating capacity(-10℃) | W | 100 | 100 | 200 | 300 | |
| Annual energy consumption | Cooling | kwh/a | 149 | 195 | 293 | 390 |
| Average | kwh/a | 700 | 735 | 1330 | 1680 | |
| Moisture removal | Liters/h | 1 | 1.2 | 1.5 | 1.8 | |
| Indoor sound power(S/H/M/L/Mute) | dB(A) | 50/47/43/35/32 | 50/47/43/35/32 | 53/50/47/43/36 | 54/51/48/44/40 | |
| Outdoor sound power | dB(A) | 60 | 60 | 65 | 67 | |
| Electrical Data | ||||||
| Power supply side | Outdoor | Outdoor | Outdoor | Outdoor | ||
| Operating current | Cooling | A | 4.0(1.2~8.0) | 5.8(1.5~9.0) | 8.1(1.7~12.0) | 10.7(2.3~12.3) |
| Heating | A | 3.8(1.2~9.0) | 5.1(1.5~10.0) | 7.0(1.7~13.0) | 9.9(2.3~13.5) | |
| Power consumption | Cooling | W | 825(240~1380) | 1130(290~1500) | 1580(330-2340) | 2257(410~2824) |
| Heating | W | 767(240~1552) | 1005(290~1720) | 1374(340-2520) | 2063(420~3005) | |
| Refrigerating System | ||||||
| Refrigerant type/Charge/GWP/CO2 equivalent | R32/0.45kg/675/0.304tonnes | R32/0.49kg/675/0.331tonnes | R32/1kg/675/0.675tonnes | R32/1.14kg/675/0.770tonnes | ||
| Compressor | Type | Rotary | Rotary | Rotary | Rotary | |
| MFG | RECHI | RECHI | GMCC | SANYO | ||
| Indoor air circulation Cooling/heating | m3/h | 420/420 | 550/550 | 800/800 | 980/980 | |
| Indoor fan type | Cross Flow | Cross Flow | Cross Flow | Cross Flow | ||
| Outdoor fan type | Propeller fan | Propeller fan | Propeller fan | Propeller fan | ||
| Connections | ||||||
| Connecting Wiring | Core x Size | 4×0.75mm² | 4×0.75mm² | 4×0.75mm² | 4×0.75mm² | |
| Expension device | Expension device | Expension device | Expension device | Expension device | ||
| Connecting Pipe | Gas | Inches | 3/8" | 3/8" | 3/8" | 1/2" |
| Liquid | Inches | 1/4" | 1/4" | 1/4" | 1/4" | |
| Others | ||||||
| Application area | m² | 9~16 | 14~22 | 20~35 | 27~45 | |
| Max. refrigerant pipe length | m | 25 | 25 | 25 | 25 | |
| Max. difference in level | m | 10 | 10 | 10 | 10 | |
| Operation temperature range | ℃ | 16-31 | 16-31 | 16-31 | 16-31 | |
| Ambient temperature range | Outdoor | ℃ | Cooling:-15-53/Heating:-20-30 | Cooling:-15-53/Heating:-20-30 | Cooling:-15-53/Heating:-20-30 | Cooling:-15-53/Heating:-20-30 |
| Indoor | ℃ | Cooling:17-32/Heating:0-30 | Cooling:17-32/Heating:0-30 | Cooling:17-32/Heating:0-30 | Cooling:17-32/Heating:0-30 | |
