Auto Paint Stop Air Filter Spray Booth Fiberglass Media Floor Filter Rolls
- Category: >>>
- Supplier: Guangzhou Clean-Link Filtration Technology Co. Ltd.
Share on (1601040808261):
Product Overview
Description
Product Description
1.Made of long fiberglass in non-woven way, large ventilation quantity, small resistance, good efficiency of the dust arrestance for the over-spray.
2.It is applied to the superficial spray coating high quality painting-spray filtration, high dust catching, specially , PA-50/60/PA-100 is suitable for using heat recovery system
3.High strength fiberglass increasing structure; the windward side is green ,the leeward side is white.
4.The low compression performance maintains its outlook,which is completely useful for the filtration fibre to keep the oil mist and the dust
5.Nonflammability, heat resistance 170℃
6.The compression packing may save the fare and the storage space in the transportation. After decompression, it will regain its original condition
7.Outer frame may choose the paper frame , the galvanization iron frame, or aluminium alloy frame.
2.It is applied to the superficial spray coating high quality painting-spray filtration, high dust catching, specially , PA-50/60/PA-100 is suitable for using heat recovery system
3.High strength fiberglass increasing structure; the windward side is green ,the leeward side is white.
4.The low compression performance maintains its outlook,which is completely useful for the filtration fibre to keep the oil mist and the dust
5.Nonflammability, heat resistance 170℃
6.The compression packing may save the fare and the storage space in the transportation. After decompression, it will regain its original condition
7.Outer frame may choose the paper frame , the galvanization iron frame, or aluminium alloy frame.
Model | PA-50/60 | PA-100 | ||
Thickness | 50/60mm | 100mm | ||
Weight | 240g/㎡ | 320g/㎡ | ||
Wind Velocity Test | 0.7-1.5m/s | 0.7-1.5m/s | ||
Initial Resistance | 15Pa | 20Pa | ||
Final Resistance | 250Pa | 280Pa | ||
Temperature Resistance | 170°C | 170°C | ||
Dust holding Capacity | 3200-3600g/㎡ | 3600-4900g/㎡ | ||
Average Weight Efficiency | 93% | 96% | ||
*To make customized sizes and thicknesses is available. | ||||
Products Details
Production Application
Related Products
Company Information
Our Advantages
Exhibition & Certificate
FAQ
1. We have specialized in the export of air filters for over 11years.
2. We have our own factory and brand.
3. We provide OEM and ODM service ,sample production and service according to your demand
4. The dimension can be customized.
5. The products have passed ISO9001,ULand SGS certification.
6. With independent R&D and design capablities.
2. We have our own factory and brand.
3. We provide OEM and ODM service ,sample production and service according to your demand
4. The dimension can be customized.
5. The products have passed ISO9001,ULand SGS certification.
6. With independent R&D and design capablities.
