Lumiax 30A 12v 24v USB LCD display PWM solar charge controller
- Category: >>>
- Supplier: Qingdao Skywise Technology Co. Ltd.
Share on (1601040972852):
Product Overview
Description
Product Description
MAX20-EU | MAX30-EU | MAX40-EU | |||
System voltage | 12/24V automatic recognition | ||||
Max charging current | 20A | 30A | 40A | ||
Fast Voltage | ＜14.5V/29V(25℃） | ||||
Boost voltage | 14.5V/29.0V (25 °C ) | ||||
Equal voltage | 14.8V/29.6V (25 °C )(Liquid,AGM) | ||||
Float voltage | 13.7V/27.4V (25 °C ) | 13.7V/27.4V (25 °C ) | |||
Max solar voltage | 55V | ||||
Day/Night threshold | 8.0/16.0V | ||||
USB interface | 5A,2A | 5V,2A | |||
Max load current | 20A | 30A | 40A | ||
Ambient temperature | -20 °C ~+50°C | ||||
Work modes | Always on,Dusk to Dawn,Evening,Manual | ||||
Storage Temperature | -25°C ~+80°C | ||||
Protection degree | IP32 | ||||
Package and Shipping
Pacakge:
Single package size:200*110*65mm
Single gross weight:0.8kg
Package Type:20 pcs/Carton 430*430*360mm
G.W:10.6kg
Single gross weight:0.8kg
Package Type:20 pcs/Carton 430*430*360mm
G.W:10.6kg
