Single Colors Plastic Bag Label Printer Flexo Printing Machine Flexographic Printer
$34,000.00-35,000.00
Four Colour Flexo Printing Machine Plastic Film Single Color Flexo Printing Machine One Color Flexographic Machine
- Category: >>>
- Supplier: Zhejiang Kete Machinery Co. Ltd.
Share on (1601040997930):
Product Overview
Description
This Stack Type Flexo Printing Machine Is Suitable for Roll-To-Roll Printing Plastic Film, Paper, Non Woven Fabric, PP Woven Fabric, Aluminum Foil, And Other Similar Roll Type Materials.
● Unwind and Rewind with Auto Tension Control
● Ceramic Anilox Roller uses the Japanese brand
● Printing Cylinder Life uses a Hydraulic System
● Unidirectional Bearing uses Germany ASNU Brand
● Optional: UV Drying System
● Optional: Rubber Plate Mounting Machine
● PLC Touch Screen Control System
● Double Side Enclosed Type Doctor Blade
● Most Bearings use Japan NSK Brand
● Optional: Shaft Type Auto Loading
● Optional: Web Video Inspection
● Optional: Ceramic Anilox Roller Ultrasonic Clean Machine
Model | KTFP-S120 |
Printing Color | 2/4/6/8/10 colors |
Raw Material Width | 600-2400mm (23.6” - 94”) |
Printing Length (Repeat) | 190-889mm (7.5”- 35”) Up to 2032mm (up to 80") |
Max. Mechanical Speed | 120m/min |
Max. Printing Speed | 100m/min (Plastic Film) 110m/min (Paper) |
Ceramic Anilox Roller | 200 - 800LPI (Japan Brand) |
Rubber Plate Thickness | 1.14mm /1.7mm / 2.28mm |
Doctor Blade | Double-Side Enclosed Type |
Color Register Precision | ±0.15mm (Vertical/ Horizontal) |
Unwind and Rewind Diameter | Φ600 /Φ800mm (23.6”/31.5”) |
Paper Core Inner Diameter | Φ76mm (3”) |
Ink | Water Based /Solvent Based |
Tension Range | 3-50kg |
Tension Precision | ±0.3kg |
Air Supply | 0.6Mpa |
Drying Way | Electrical Heating |
Power Support | 3 Phase 220/380/440V 50/60HZ |
