UG 650 Insulation Fireproof Aerogel Blanket With Low Thermal Conductivity For Construction

Product Overview

Description



Zhejiang UgooTechnology Co., Ltd. was established in 2017, with a registered capital of 100 million yuan, covering an area of 100 mu, located in high-tech Development Zone of Yiwu City, Zhejiang Province. The total investment of the silica aerogel project is 800 million yuan, and the annual output of aerogel composite materials is 4 million square meters, becoming a domestic industry leader with strong technical strength and first-class equipment and facilities.



Aerogel is a new nano material which is formed by the condensation of colloidal particles or polymer molecules, and then the liquid in the gel pores is replaced by gas by a special drying process while the gel skeleton structure does not collapse.

The unique three-dimensional mesh porous structure of aerogel makes it not only low thermal conductivity, but also sound absorption, noise reduction, pressure and impact resistance, and has the characteristics of class A fire prevention and overall hydrophobic, which is far better than other traditional thermal insulation materials.

As a new type of nanomaterial, aerogel has been widely used in aerospace, naval ships, high-speed rail vehicles, new energy vehicles, electric power, petrochemical, solar thermal, construction and other fields.

UG550 Product Features UG550 series is a high temperature product, the recommended temperature is 250℃~550℃. High temperature insulation performance is excellent, mainly used in oil refining, chemical, electric power, nuclear energy, metallurgy, solar thermal and other fields of high temperature pipeline and equipment insulation.



Data of UG550
No.	Average temperature (*C)	Thermal Conductivity(W/ mK) UG550	Thermal Conductivity(W/ mK) UG550S
1	25	0.021	0,019
2	100	0.025	0.0251
3	200	0.028	0.03
4	300	0.036	0.0352
5	400	0.048	0,.0447
6	500	0.072	0.062
7	600	0.110	0.0909
No.	Property
8	Length (m)	40m	40m
9	Width (mm)	1500mm±5	1500mm±5
10	Thickness (mm)	5mm,10mm (Other thickness can be customized)	5mm,10mm (Other thickness can be customized)
11	Density  (kg/m3)	200 ±20	200 ±20
12	tensile strength (kpa)	transverse ≥1500,  vertical ≥500	transverse ≥1500,  vertical ≥500
13	Hydrophobicity Rate	≥98%	≥98%
14	Soluble CL content(ppm)	≤10	≤10
15	Compression rebound rate(%)	≥90	≥90
16	Heating permanent line change(650℃,%)	≥-0.8	≥-0.8
17	fire rating	A2	A2
18	Recommended long-term use temperature	≤550℃	≤550℃





Main Business:Development and production of aerogel and its composite materials



Establishment Date: 2017



Factory Address: Yiwu City, Zhejiang Province



Registered Capital: 100 million CNY



Factory Area: 66,000m2



Total Investment: 500 million CNY



Designed Capacity: 4 million m2 (2.5 million m2 completed)





The thermal conductivity is low

The thermal conductivity is 1 / 3-1 / 5 of the traditional materials. In the same case of surface heat dissipation loss, the thermal insulation thickness is thinner, the line heat dissipation loss is smaller, the energy saving is more than 30%, and the transportation load is small.

Good waterproof performance, no corrosion

The moisture repellent rate is 98%, no need for special waterproof, rainwater immersion does not disintegrate and settle, and the preparation process does not contain chloride ions, which is not easy to cause pipeline corrosion.

Use with a wide temperature range

Long-term adiabatic use at-260℃ ~550℃ temperature. Long-term use at high temperature without melting, very low temperature under the unchanged brittle.

Good fire performance

With completely non-combustible grade A fire resistance. It is safer to use, can be used for any fire prevention situation, no melting drops, avoid secondary combustion, not toxic gas decomposition in the fire site.

Good mechanical properties, with a long service life

Tensile strength 500 KPa, deformation 25% under 80 Kpa pressure, and compression rebound rate 90%. Convenient construction, less solid waste, vibration does not settle, long-term stable performance.

Environmental protection without harm

Amorphous silica, no harm to the human body
