China large size HDPE floating dredger equipped with 450MM HDPE pipe floating body

Product Overview

Description

China large size HDPE floating dredger equipped with 450MM HDPE pipe floating body





Brief Introduction:
The hull of MDPE FLOATER is made from medium density polyethylene material with excellent flexibility, filled with high strength polyurethane foam inside. With reasonable structure and good performance, the MDPE floater becomes the ideal substitution of the traditional steel floater for the floating dredging pipes.

Characteristics:

1.Good flexibility
Excellent impact resistance, particularly suitable for constructions in open sea.
2. Light weight
Easy to install and handle, lower costs for moving.
3. Higher corrosive resistance
Longer working life, 3 times longer than steel floaters.
4. Lower costs
The cost performance is better than steel floaters.



Applications:
1.Used in dredging sand pipeline;
2.It can be used in dredger, dredging pipe etc. in the sea, lake or river;
3.Particular used in laying the pipes on the water used in dredger project.

Remarks:
1. 2 pieces of floaters form 1 set, 2 sets of floaters form 1 pair. 1 pair of floaters could float 6 meter long steel dredging pipe and 1.5m long rubber hose.
2. The floaters under the size of O.D4m*L4m are all available



Technical literature:

Structure of Floater for Dredging Pipe
No.	Structure Name	Material
1	Polyethylene Hull	Polyethylene
2	Hard Polyurethane Foam	Closed-cell Polyureshane
3	Steel Bolts & Nuts	Metal



Main Technical Properties
Item	Technical Index of Hull	Item	Inside Technical Index
Tensile Strength	≥13.1MPa	Water Absorption	1-2g/100cm2
Bteak Elingation	≥11.1%	Breaking Strength	0.08-0.1MPa
Impact Strength	≥32.4KJ/m2	Breaking Elingation	4-6%
Bending Strength	≥15.7 MPa	Compressive Strength	0.1-0.24MPa
Weather Resistance≥3.5GJ/m2 After tital aging energy≥3.5GJ/m2	Break Elingation    %≥		10
	200°Cmm≥ Oxidative Induction Time 200°Cmm≥		10
