frameless glass stacking windows sliding separately transparent folding windows for balcony glazing
- Category: >>>
- Supplier: Shanghai Finzone Windows & Doors Co. Ltd.
Share on (1601043044366):
Product Overview
Description
Product Details
frameless glass stacking windows sliding separately transparent folding windows for balcony glazing
| Popular system: | Finzone09 is used for most kinds of balcony shape, specially for flat balcony. |
| Stronger profiles: | The upper track is 3mm thickness and importance of the point is 5mm thick; the width of glass profile is 29mm and the height is 41mm, the importance of the point is 2.5mm thick. |
| Glass: | Use 8mm tempered glass and 5+4 laminated glass. |
| Big panels: | The max width for glass panel is 650mm and the height is 2300mm. |
| Protection cap: | Apply nylon protection cap on glass profiles to avoid hurting. The protection is laddy-like and the sealing is better for glass panels. |
| Better Rollers: | Use big bearing wheels and slide smoothly. The width of one bearing wheel is 36mm and the height is 11mm. |
| Best sealing: | There is no gap between track profiles and glass profiles. There is no gap between the first and last glass panels with side profiles. |
| Hinge axles: | Use SS304 for hinge axles so that can stand big weight and avoid the glass panels falling down. |
| No rivets: | Apply specially glue to connect glass and glass profile, there is no any rivets and holes in glass profile. |
| Connection hardware: | Use SS304 to connect the track profiles to ensure the stablity of connection. |
| Profile material: | Used Aluminum alloy 6063T5 material for profiles, the surfaces are treated with static electroplating spray. |
glass curtain
Company introduction
Finzone is professional in the frameless balcony glazing system over the last 11 years. As the manufacturer and exporter of frameless balcony glazing system, we have many clients in more than 30 countries around the world, especially in Europe such as Finland, Sweden, Spain, Poland, etc. We can provide material to wholesale customers and also assembled products to retail and project customers. We have more than 5 different systems can meet different demands on balcony, terrace, patio, sunroom, even partition wall.
glass curtain
Show Case
glass curtain
Factory introduction
glass curtain
Our Exhibition
glass curtain
Certifications
glass curtain
