Datacard CR805 Single Sided Retransfer Card Printer Datacard Printer
- Category: >>>
- Supplier: Shenzhen Baote Card Barcode Technology Co. Ltd.Shenzhen Ltd.
Share on (1601043224265):
Product Overview
Description
Product Description
Specification
Print Technology | Retransfer pigment ink |
Brand | Datacard |
Model | CR805 |
Printing | Single sided or dual sided |
Single-sided (CMYKP) | up to 110 cards per hour (cph) |
Double-sided (CMYKP-KP) | up to 65 cards per hour (cph) |
Entrust Artista CR805 Retransfer Card Printer (formerly Entrust Datacard CR805 Retransfer Card Printer)
Print Technology
* Retransfer pigment ink
Print Capabilities
* Single- or dual-sided, over-the-edge printing
Print Resolution
* 600 dots per inch (dpi)
Print Speed
* Full color printing * Single-sided (CMYKP) - up to 110 cards per hour (cph)
* Double-sided (CMYKP-KP) - up to 65 cards per hour (cph)
Color Modes
* True Color (ICC) - prints color as close as possible to image as defined in the card design
* Legacy SR/CR - prints color as close as possible to the SR200, SR300, and SR300e card printers
Card Capacity
* Input hopper - 125 cards
* Output hopper - 25 cards (optional 125 card)
* Card input size - 0.030 inches to 0.040 inches (0.76 mm to 1.01mm)
Operating Environment
* 60°F - 95°F (15°C - 35°C)
Physical Dimensions
* L 21.4 in. x W 10.1 in. x H 15.6 in.
* L 54.34 cm x W 25.53 cm x H 39.68 cm
Weight
* 28 lb. (12.7 kg); with options will vary
Connectivity
* USB and Ethernet
Magnetic Stripe Encoding
* ISO/IAT Magnetic Stripe Encoding
* JIs Magnetic Stripe Encoding
SmartCard Encoding
Single wire - Contact ISO 7816 T=0, 1
* Contactless ISO 14443 A/B Protocols,
* Mifare Protocols & FeliCa (DES & AES)
Loosely Couple - Contact ISO 7816 T=0, 1
* Contactless ISO 14443 A/B Protocols, Mifare Protocols & FeliCa
* HID iCLASS, Read/write or read-only encoder
* PC Prox
Primeless Color Panel Ribbons and Retransfer Film
* CMYK: 1,000 images single-sided (500 dual-sided)
* CMYK-K: 1,000 images dual-sided
* Clear Retransfer Film: 1,000 images single-sided (500 dual-sided)
Color Ribbons with Primer Panel and Retransfer Film
Two options:
* CMYKP-KPi: 500 images dual-sided
* FCMYP-KPi: 750 images dual-sided
* Clear Retransfer Film: * 1,500 images single-sided (750 dual-sided)
* 1,000 images single-sided (500 dual-sided)
Print Technology
* Retransfer pigment ink
Print Capabilities
* Single- or dual-sided, over-the-edge printing
Print Resolution
* 600 dots per inch (dpi)
Print Speed
* Full color printing * Single-sided (CMYKP) - up to 110 cards per hour (cph)
* Double-sided (CMYKP-KP) - up to 65 cards per hour (cph)
Color Modes
* True Color (ICC) - prints color as close as possible to image as defined in the card design
* Legacy SR/CR - prints color as close as possible to the SR200, SR300, and SR300e card printers
Card Capacity
* Input hopper - 125 cards
* Output hopper - 25 cards (optional 125 card)
* Card input size - 0.030 inches to 0.040 inches (0.76 mm to 1.01mm)
Operating Environment
* 60°F - 95°F (15°C - 35°C)
Physical Dimensions
* L 21.4 in. x W 10.1 in. x H 15.6 in.
* L 54.34 cm x W 25.53 cm x H 39.68 cm
Weight
* 28 lb. (12.7 kg); with options will vary
Connectivity
* USB and Ethernet
Magnetic Stripe Encoding
* ISO/IAT Magnetic Stripe Encoding
* JIs Magnetic Stripe Encoding
SmartCard Encoding
Single wire - Contact ISO 7816 T=0, 1
* Contactless ISO 14443 A/B Protocols,
* Mifare Protocols & FeliCa (DES & AES)
Loosely Couple - Contact ISO 7816 T=0, 1
* Contactless ISO 14443 A/B Protocols, Mifare Protocols & FeliCa
* HID iCLASS, Read/write or read-only encoder
* PC Prox
Primeless Color Panel Ribbons and Retransfer Film
* CMYK: 1,000 images single-sided (500 dual-sided)
* CMYK-K: 1,000 images dual-sided
* Clear Retransfer Film: 1,000 images single-sided (500 dual-sided)
Color Ribbons with Primer Panel and Retransfer Film
Two options:
* CMYKP-KPi: 500 images dual-sided
* FCMYP-KPi: 750 images dual-sided
* Clear Retransfer Film: * 1,500 images single-sided (750 dual-sided)
* 1,000 images single-sided (500 dual-sided)
FAQ
1. What is the datacard CR805 retransfer ID card printer?
The new Datacard CR805 retransfer printer uses pigment ink along with 600 dpi printing results to offer high-resolution cards that are not susceptible to UV fading. The end result, high-quality cards that last longer lowering your costs.
2. how does CR805 work?
The CR805 card printer features Datacard proprietary ribbons which are designed specifically for use in Entrust Datacard series card printers. When the printer recognizes that a Datacard supply is installed, all enhanced product features are enabled and successful card printing can begin.
3.How about Datacard CR805?
The CR805 can print up to 100 single-sided, single-sided lamination cards per hour, or 66 dual-sided cards with lamination.
Datacard's unique patent-pending tactile impression creates card security you can see and feel. Using a tactile impression die, a design is physically impressed into your card.
4. What ribbon does the Datacard CR805 use?
Entrust Datacard CR805 CMYKP-KP Color Ribbon card printer ribbon kits include all necessary cleaning supplies for the CR805 card printer's daily operations.
5. What are the options for Datacard CR805?
Single sided and dual sided
The new Datacard CR805 retransfer printer uses pigment ink along with 600 dpi printing results to offer high-resolution cards that are not susceptible to UV fading. The end result, high-quality cards that last longer lowering your costs.
2. how does CR805 work?
The CR805 card printer features Datacard proprietary ribbons which are designed specifically for use in Entrust Datacard series card printers. When the printer recognizes that a Datacard supply is installed, all enhanced product features are enabled and successful card printing can begin.
3.How about Datacard CR805?
The CR805 can print up to 100 single-sided, single-sided lamination cards per hour, or 66 dual-sided cards with lamination.
Datacard's unique patent-pending tactile impression creates card security you can see and feel. Using a tactile impression die, a design is physically impressed into your card.
4. What ribbon does the Datacard CR805 use?
Entrust Datacard CR805 CMYKP-KP Color Ribbon card printer ribbon kits include all necessary cleaning supplies for the CR805 card printer's daily operations.
5. What are the options for Datacard CR805?
Single sided and dual sided
