EN 344 Safety Shoes Drop Impact Testing Machine, Safety Footwear Impact Tester, BS ANSI Standard Safety Shoes Impact Tester
- Category: >>>
- Supplier: Dongguan Yinhong Electronic Equipment Co. Ltd.
Share on (1601044389734):
Product Overview
Description
Products Description
EN 344 Safety Shoes Drop Impact Testing Machine,
Safety Footwear Impact Tester, BS ANSI Standard Safety Shoes Impact Tester
Safety Footwear Impact Tester, BS ANSI Standard Safety Shoes Impact Tester
Summary
This Safety Shoes Footwear Impact Resistance Tester is installed a steel striker adaptered to fall freely on vertical guides from a predetermined height to give the required impact energy to the toe of safety footwear for measuring the degree of the dent. In addition, the toecap should not develop any cracks on the test axis with go through the material.
The machine is mainly used to conduct impact test on steel head of safety shoes, and then inspect its subsidence degree to understand the safety quality of safety shoes.
The machine is mainly used to conduct impact test on steel head of safety shoes, and then inspect its subsidence degree to understand the safety quality of safety shoes.
Standards
ASTM-D1790,D1593,1052,JIS-K6545,HB-T2877,CNS-7705,ISO 20344,GB/T20991-2007 Etc
Main Specifications:
Item | YH-351 Safety Shoes Drop Impact Testing Machine |
Impact Weight | (EN) 20±0.2kg, (BS, ANSI) 22.7KG |
Drop Height | 0~1100mm auto adjustable |
Impact Energy | (EN)200J, (BS, ANSI)100J |
Striker | (EN)3±0.1mm, (ANSI) ø25.4 |
Dimension | 70×70×180cm |
Weight | 185kg |
Power | AC220V/50Hz or specified |
Function instruction
(up): Control the beam and its rise when it grips the impact head
(down):Control the beam and its fall when it grips the impact head
ON/OFF:Switch on the control panel
(release):The impact falls down (the test method is as follow)
Note :The impact speed in the range of 4.35~4.5 is normal
(The speed is shown on the speed chart)
(down):Control the beam and its fall when it grips the impact head
ON/OFF:Switch on the control panel
(release):The impact falls down (the test method is as follow)
Note :The impact speed in the range of 4.35~4.5 is normal
(The speed is shown on the speed chart)
Product packaging
We have professional packing teams and shipping forwarder to pack and deliver your products!
Packing:
1. Out packing:Standard export wooden case.
2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.
Shipping:
You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt of your order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.
Packing:
1. Out packing:Standard export wooden case.
2. Inner packing:With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.
Shipping:
You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt of your order. It's more preferable for you to provide us with your own FEDEX/DHL account number so that the delivery charge can be charged directly from your account.
