voltage regulator relay AVS AVR wall mounted
- Category: >>>
- Supplier: Zhejiang Sanke New Energy Co. Ltd.
Share on (1601045465247):
Product Overview
Description
AC automatic voltage regulator TMB 5k 10k 15k 20k 30k
static relay type automatic voltage regulator TMB series
Specification
Product | Technology | Paremeter |
Input | voltage | AC 95-280V |
Input | Phase | Single Phase |
Inp | Frequency | 50Hz/60Hz |
Output | Voltage Range | AC220V |
Precision | ±10% | |
Frequency | 50Hz/60Hz | |
Power Factor | 80% | |
Function | Control Type | Relay Type |
Over/Low Volt Protection | Yes | |
Over-Current Protection | Yes | |
Digital Display | Show input and output voltage | |
Delaying | 6Secs(short)/180Secs(long) | |
Short Circuit& Over Load | MCB | |
Effciency | AC-AC | 0.96 |
Acoustic | Noise Level | ≤50dB |
Temperature | -5-60 Degree | |
Humidity | 20% to 90% |
The automatic voltage regulator/stabilizer with high precision digital display.
Comprehensive monitoring to ensure the safety of the product operation.
AC automatic voltage regulator TMB 5k 10k 15k 20k 30k
