Stainless Steel Pipe Swivel Joint Fittings Hydraulic Adapter Factory Spot Sales

代 号
PART NO.

螺 纹THREAD

管子外径TUBE O.D

E,F.G

D1 ,D2 ,D3

AC-08

M8X1

4

AC-10

M10X1

5

AC-10A

M10X1

6

AC-12A

M12X1

8

AC-12

M12X1.5

6

AC-14

M14X1.5

8

AC-16

M16X1.5

10

AC-18

M18X1.5

12

AC-22

M22X1.5

15

AC-26

M26X1.5

18

AC-30

M30X2

22

AC-36

M36X2

28

AC-45

M45X2

35

AC-52

M52X2

42

AD-14

M14X1.5

6

AD-16

M16X1.5

8

AD-18

M18X1.5

10

AD-20

M20X1.5

12

AD-22

M22X1.5

14

AD-24

M24X1.5

16

AD-30

M30X2

20

AD-36

M36X2

25

AD-42

M42X2

30

AD-52

M52X2

38

代 号
PART NO.

尺 寸 DIMENSIONS

压力等级
MPa

111,213

L1,L2,L3

SI

S2,S3,S4

AC-08

11

21

9

10

10
特轻系列
LL

AC-10

9.5

21

9

12

AC-10A

9.5

21

9

12

AC-12A

11.5

23

12

14

AC-12

12

27

12

14

25
轻系列
L

AC-14

14

29

12

17

AC-16

15

30

14

19

AC-18

17

32

17

22

AC-22

21

36

19

27

AC-26

23.5

40

24

32

AC-30

27.5

44

27

36

16
轻系列
L

AC-36

30.5

47

36

41

AC-45

34.5

56

41

50

AC-52

40

63

50

60

AD-14

16

31

12

17

63
重系列
S

AD-16

17

32

14

19

AD-18

17.5

34

17

22

AD-20

21.5

38

17

24

AD-22

22

40

19

27

AD-24

24.5

43

24

30

40
重系列
S

AD-30

26.5

48

27

36

AD-36

30

54

36

46

AD-42

35.5

62

41

50

AD-52

41

72

50

60

31.5重系列S

注：如需带卡套及卡套螺母整套订货，则请在代号后加“RN”,如AC-22RN。
Note:In case if you are interested to order the adapter in complete set with cutting ring
and nut ,it is necessary to insert suffix "RN after our part no.,for example AC-22RN.
