non-woven geotextile | ||||||||||||||
item | Specification | |||||||||||||
20-15 | 30-22 | 40-28 | 50-35 | 60-42 | 80-56 | 100-70 | ||||||||
Vertical Breaking strength(KN/M≥) | 20 | 30 | 40 | 50 | 60 | 80 | 100 | |||||||
horizontal Breaking strength(KN/M≥) | 15 | 22 | 28 | 35 | 42 | 50 | 70 | |||||||
vertical Elongation at break(%) | 28 | |||||||||||||
CBR Bursting strength(KN) | 1.6 | 2.4 | 3.2 | 4 | 4.8 | 6 | 7.5 | |||||||
Vertical permeability coefficient(cm/s) | 0.0001-0.01 | |||||||||||||
Unit area weight(g/㎡) | 120 | 160 | 200 | 240 | 280 | 340 | 400 | |||||||
Deviation rate(%) | ±10 |
