Factory Direct CE Rear Wheel 48V 250W 350W Bicycle Hub Motor Ebike Conversion Kit Bicycle Motor Kit
- Category: >>>
- Supplier: Changzhou Found Environmental Technology Co. Ltd.
Share on (1601047662076):
Product Overview
Description
Specification
Item | Value |
Design | Brushless Geared |
Position | Rear Wheel Hub Motor |
Wheel Size | 16''-29'' |
Color | Black or Silver |
Power | 250W-350W |
Brake Type | Disc/V brake |
Voltage | 24V/36V or 36V/48V |
PAS | Double Hall 12 Magnets |
Place of Origin | China |
Efficiency | ≥82% |
Application | Electric Bicycle |
Open Size | 125mm or 135mm |
Rated Speed | 25km/h-35km/h |
Certification | CE CCC ROHS FCC |
MOTOR OPEN SIZE
MTB/Normal electric bike1.Front drive motor:100mm
2.Rear drive single speed motor: 125mm
3.Rear drive 6-9speed motor: 135mm
4.Rear drive cassette:140mm
Fat bike/Snow bike
1.Front drive motor:130-140mm
2.Rear drive motor:170-190mm
Single speed, 6-9speed,cassette motor optional.
Electric motorcycle
180-200mm.
1.Q: Is it available for sample?
A:Yes. We offer sample, but free sample are not available at beginning.
2.Q: What's your warranty for products?
A: a.) If you import goods from us, we will be full refunds protection if goods itself has quality problems.
b.) We can return your money if you are not satisfied with our product within 7 days after you get the goods, you only need take
the freight.
c.) We promise to replace the goods freely if there are some problems within 6months.
d.) We promise 2 years' warranty. First year, exchanging products for free and second year, maintenance free. You only need to do
is pay the freight.
3.Q:What our motors’ max rotaing speed?
A:350RPM—1200RPM
4.Q:How much voltage we can do for motors?
A:24V,36V,48V,60V,72V,96V as your required.
5.Q:How much power we can do for motors?
A: Electric bike motor 180W-5000W.
A:Yes. We offer sample, but free sample are not available at beginning.
2.Q: What's your warranty for products?
A: a.) If you import goods from us, we will be full refunds protection if goods itself has quality problems.
b.) We can return your money if you are not satisfied with our product within 7 days after you get the goods, you only need take
the freight.
c.) We promise to replace the goods freely if there are some problems within 6months.
d.) We promise 2 years' warranty. First year, exchanging products for free and second year, maintenance free. You only need to do
is pay the freight.
3.Q:What our motors’ max rotaing speed?
A:350RPM—1200RPM
4.Q:How much voltage we can do for motors?
A:24V,36V,48V,60V,72V,96V as your required.
5.Q:How much power we can do for motors?
A: Electric bike motor 180W-5000W.
Specification
Item | Value |
Design | Brushless Geared |
Position | Rear Wheel Hub Motor |
Wheel Size | 16''-29'' |
Color | Black or Silver |
Power | 250W-1000W |
Brake Type | Disc/V brake |
Voltage | 24V/36V or 36V/48V |
PAS | Double Hall 12 Magnets |
Place of Origin | China |
Efficiency | ≥82% |
Application | Electric Bicycle |
Open Size | 125mm or 135mm |
Rated Speed | 25km/h-50km/h |
Certification | CE CCC ROHS FCC |
MOTOR OPEN SIZE
MTB/Normal electric bike1.Front drive motor:100mm
2.Rear drive single speed motor: 125mm
3.Rear drive 6-9speed motor: 135mm
4.Rear drive cassette:140mm
Fat bike/Snow bike
1.Front drive motor:130-140mm
2.Rear drive motor:170-190mm
Single speed, 6-9speed,cassette motor optional.
Electric motorcycle
180-200mm.
1.Q: Is it available for sample?
A:Yes. We offer sample, but free sample are not available at beginning.
2.Q: What's your warranty for products?
A: a.) If you import goods from us, we will be full refunds protection if goods itself has quality problems.
b.) We can return your money if you are not satisfied with our product within 7 days after you get the goods, you only need take
the freight.
c.) We promise to replace the goods freely if there are some problems within 6months.
d.) We promise 2 years' warranty. First year, exchanging products for free and second year, maintenance free. You only need to do
is pay the freight.
3.Q:What our motors’ max rotaing speed?
A:350RPM—1200RPM
4.Q:How much voltage we can do for motors?
A:24V,36V,48V,60V,72V,96V as your required.
5.Q:How much power we can do for motors?
A: Electric bike motor 180W-5000W.
A:Yes. We offer sample, but free sample are not available at beginning.
2.Q: What's your warranty for products?
A: a.) If you import goods from us, we will be full refunds protection if goods itself has quality problems.
b.) We can return your money if you are not satisfied with our product within 7 days after you get the goods, you only need take
the freight.
c.) We promise to replace the goods freely if there are some problems within 6months.
d.) We promise 2 years' warranty. First year, exchanging products for free and second year, maintenance free. You only need to do
is pay the freight.
3.Q:What our motors’ max rotaing speed?
A:350RPM—1200RPM
4.Q:How much voltage we can do for motors?
A:24V,36V,48V,60V,72V,96V as your required.
5.Q:How much power we can do for motors?
A: Electric bike motor 180W-5000W.
