Shantui 320HP Crawler Track Bulldozer SD32 Bulldozer With Front Blade
Contact Info
Products Description
The SD32 provides a showcase for Shantui's prowess with high-efficiency push factors. These medium-sized, but heavy-duty machines designed for earth-moving projects get the biggest, toughest jobs done quickly and efficiently. SD32 are equipped with a hydraulic drive system with hydraulic control technology and an advanced structure, which provide reliable performance and convenient and flexible operation.
Chongfa NTAA855-C360S10 engine is quipped with exhaust gas turbocharger, featuring trong power and high efficiency and energy-saving, and can work normally even in the highlands as high as 3,600m. Depending on the customers’ demands, the option Cummins and Weichai engines are available.
The high reliability power shift transmission, the stable hydraulic torque converter, and two-stage spur gear final drive feature high power transmission capacity and efficiency and high productivity.
The independent engine water tank, the chassis oil cooler, and the water-air intercooler integrated in the Chongfa engine provide prominent cooling performance and simple maintenance operations to guarantee the continuous working of the machine.
The full box-type main frame with application of high performance materials and high strength castings features high carrying capacity against impact load and bending moment to support the continuous high-strength working of machine under severe working condition and the high quality welds guarantee the life cycle of the main frame.
The low-drive final drive can provide powerful drive force and efficient gradeability. Shantui's crawler chassis has reached the international advanced level in process level and can adapt to various complicated working conditions, featuring high reliability and carrying capacity.
The standard straight tilting blade features powerful cutting force and the single-shank and three-shank rippers of adjustable penetrating angle can be used for the ripping of clay and frozen earth as well as the stripping of hard working faces, such as gravel and hardened salt mine.
Product Paramenters
MODEL | SD32 |
Operating weight (kg) | 37200kg |
Dozing capacity (m3) | Straight tilt blade 10 Semi-U blade 11.9 Angle blade 6 |
Engine model | NTA855-C360S10 |
Rated power (kw/rpm) | 235/2000 |
Gradeability ° | 30 |
Number of carriers (each side) | 2 |
Number of track rollers (each side) | 7 |
Number of track shoes (each side) | 41 |
Width of track shoe (mm) | 560 |
Track gauge (mm) | 2140 |
Overall Dimensions (LxWxH) | 6880x4130x3725 |
