Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
Robotic Welding Positioner Turntable Roller For Pipe Production Positioner

Robotic Welding Positioner Turntable Roller For Pipe Production Positioner

Share on (1601055699006):


Price:$2,000.00

Quantity:


Product Overview

Description



Product Description




Welding positioner
Welding positioner is a universal and efficient welding equipment that mainly realizes circular seam welding. The welding positioner can be equipped with welding power: such as argon arc welding power (wired or not filled), molten gas shielded welding power (C02/MAG/MIG welding machine), plasma welding power, flame or plasma cutting torches etc., and can be combined with other auxiliary machinery, Such as welding manipulators, robots... etc. constitute an automatic welding system.





Model
Load Capacity（Kg）
Table Speed
Table
Power

Table Dia.(mm)

Machine Size
L*W*H(mm)
Ratation （RPM）
Tilt （RPM）
Tilt Angle(°)
Ratation(Kw)
Tilt (Kw)
HBZ-1
100
0.35-3.5
1.0
0-90
0.18
0.18
400
740*525*480
HBZ-3
300
0.20-2.0
1.0
0-90
0.37
0.37
600
940*720*610
HBZ-6
600
0.09-0.9
1.0
0-90
0.75
0.75
1000
1500*1120*1000
HBZ-10
1000
0.05-0.5
0.8
0-120
1.1
1.5
1200
1850*1210*1140
HBZ-30
3000
0.05-0.5
0.23
0-120
1.5
1.5
1400
2200*1740*1355
HBZ-50
5000
0.05-0.5
0.16
0-120
2.2
3
1500
2700*1984*1510
HBZ-100
10000
0.017-0.17
0.1
0-120
3
5.5
2000
3460*2500*2024
HBZ-200
20000
0.017-0.17
0.1
0-120
4
5.5
2000
3610*2930*1974


Product Details




1.Strong load-bearing capacity Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
After the positioner’s worktable uses high-strength plates, it carried with heat treatment and finishing after welding. The table rotation adopts slewing support, which has strong load-bearing capacity.




2.Overturning angle ruler display
The positioner is equipped with ruler, and the overturning angle can be clearly displayed on the ruler, which is convenient for grasping the overturning angle.




3.Stepless variable frequency speed control
Schneider frequency converter is used to realize variable frequency speed control of worktable slewing and overturning. Robotic Welding Positioner Turntable Roller For Pipe Production Positioner




Customer Cases




About Us




Wuxi Zhouxiang Complete Set of Welding Equipment Co.,Ltd,founded in 1991,located in Wuxi city, about 100km from Shanghai.We have fixed assets of 150 million yuan,cover an area of 160,000 m2, staff 500 people,including more than 100 engineering and technical personnel.Our company was certified to ISO9001 Quality System Certification firstly in the industry and many products were certified to China Compulsory Certification(CCC).Our products sell well at home and abroad,including Europe,America,Southeast Asia,Middle East and other countries.
Zhouxiang products mainly include cnc cutting machine,H beam production line,box beam production line, welding manipulator, welding rotator, welding positioner, milling machine, shot blasting machine, plate rolling machine, profile bending machine and fiber laser cutting machine etc.We have high sincerity to do business with customers all over the world and establish good friendships. Robotic Welding Positioner Turntable Roller For Pipe Production Positioner








Our Services




FAQ


1.Q: What is the minimum order quantity?
A: 1PCS.
 Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
2.Q: What are the payment terms?
A: L/C; T/T.
 Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
3.Q: How long is the delivery time?
A: 30 Days.
 Robotic Welding Positioner Turntable Roller For Pipe Production Positioner
4.Q:How long is the warranty period?
A: 1 Years.
