Good Quality Plastic Cover Printing Machine Automatic Plastic Bag Flexographic Printers Flexo Printing Device
- Category: >>>
- Supplier: Ruian Ruihua Printing Packing Machinery Co. Ltd.
Share on (1601055905055):
Product Overview
Description
Max. Web Width | 600/800/1000/1200mm |
Max. Printing Width | 560/760/960/1160mm |
Printing Length | 400-1200mm |
Central Drum Roller | Φ1200mm |
Printing Colors | Max. 6 colors |
Printing Plate Lifting System | hydraulic control |
Max. Printing Speed | 150-200m/min |
Doctor Blade | Chamber closed type doctor blade |
Anilox Roller | Ceramic anilox roller |
Register Precision | ±0.1mm |
Printing Plate+Tape Thickness | Standard 2.38mm |
Unwind&Rewind Diameter | Φ1000mm |
Color Registration | Electric control |
Main Motor | 5.5kw with inverter control |
1. With PLC control and HMI, all the parameters are displayed on the monitor.
2. Servo motor worked as the main motor
3. With 10kg/m2 magnetic brake and clutch for unwind and rewind control
4. 2 sets automatic tension control system to provide constant tension control
5. With automatic meter counter for working length tracking.
6. All the electric appliances has been gained the CE certificate.
7. Printing rolls should keep moving while machine halted
8. High dots presentation rate with high speed; clear and vivid stratification of printing; more stereoscopic and accurate
registering precision
9. One set printing cylinder for 400mm length repeated printing.
2. Servo motor worked as the main motor
3. With 10kg/m2 magnetic brake and clutch for unwind and rewind control
4. 2 sets automatic tension control system to provide constant tension control
5. With automatic meter counter for working length tracking.
6. All the electric appliances has been gained the CE certificate.
7. Printing rolls should keep moving while machine halted
8. High dots presentation rate with high speed; clear and vivid stratification of printing; more stereoscopic and accurate
registering precision
9. One set printing cylinder for 400mm length repeated printing.
Hydraulic Unwind Station
Ink Pump Circulation
Surface Friction Rewinding
About Us
Production Process
Sample Room
Certificate
Packaging & Shipping
FAQ
Q:: Are you a factory or trading company?
A: We are manufacturer, have our own factory with over 18 years experiences.We not only sell machine for you, but offer the best solutions.
Q: Where is your factory located? How can l visit?
A: Our factory is located in Rui'an City, Zhejiang Province, China, About one hour by air from Shanghai.All our clients, from home or abroad, are warmly welcome to visit us!
Q: What kind of quality certificate do you have?
Q: What kind of quality certificate do you have?
A: We have CE certificate, SGS, ISO, etc.
Q: How does your factory do regarding quality control?
Q: How does your factory do regarding quality control?
A: Quality is the our focus. From the begining till the end of machine manufacture, we will inspect every components before using. And machine will be tested after finished.
Q: What's the payment terms?
Q: What's the payment terms?
A: We usually do TT with 30% deposit, and 70% balance paid before machine delivery. Other ways like L/C, western union,etc are also acceptable.
Q: How about the delivery time?
Q: How about the delivery time?
A: Usually, our machines can be delivered within 30 working days.
