High Frequency Online Uninterrupted UPS Power Supply 1000va 10kVA UPS with Back up Battery Power for Home Pure Sine Wave Output
- Category: >>>
- Supplier: Shangyu (shenzhen) Technology Co. Ltd.
Share on (1601059227172):
Product Overview
Description
Product Description
High Frequency Online Uninterrupted UPS Power Supply 1000va 10kVA UPS with Back up Battery Power for Home Pure Sine Wave Output
Technical data
(CONTACT FOR MORE INFORMATION)
| Model | HP1106B/H | HP1110B / H | ||||||
| PHASE | 1 phase in / 1 phase out | |||||||
| CAPACITY | 6000 VA / 5400 W | 10000 VA / 9000 W | ||||||
| Frequency Range | 46Hz ~ 54 Hz or 56Hz ~ 64 Hz | |||||||
| Power Factor | ≥ 0.99 @ 100% load | |||||||
| INPUT | 120-275VAC | |||||||
| OUTPUT | 200/208/220/230/240VAC | |||||||
| Transfer Time | 0 ms | |||||||
| Waveform | Pure Sinewave | |||||||
| BATTERY | ||||||||
| Standard Model | Battery Type | 12 V / 7 AH | 12 V / 9 AH | |||||
| QTY | 15pcs | 16pcs | ||||||
| Typical Recharge Time | 9 hours recover to 90% capacity | |||||||
| Charging Current | Default:1.0 A Max.:2.0A | |||||||
| Float Charging Voltage | 218.4 VDC ± 1% | |||||||
| Long-run Model | Battery Type | Depending on applications | ||||||
| QTY | 16-20 pcs (adjustable) | |||||||
| Charging Current | Default:4.0 A | |||||||
| Float Charging Voltage | 218.4 VDC ± 1% (based on 16 pcs batteries) | |||||||
| Standard Model | size(mm) | 515 x 250 x 608 | ||||||
| Net weight(KG) | 57 | 65 | ||||||
| Long-run Model | size(mm) | 530 x 245 x 455 | ||||||
| Net weight(KG) | 18 | 21.5 | ||||||
| Smart RS-232 | Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7, Linux, Unix, and MAC | |||||||
| Optional SNMP | Power management from SNMP manager and web browser | |||||||
Online UPS advantages:
-Power Factor 0.8/0.9(optional)
-Adopting advanced three-stage charging method
-The overall efficiency reaches 95%,ECO mode to 98%
-N+X parallel redundancy function, Max 4 parallel machines
-90% of components are from internationally renowned brands
-Abandant monitoring/communication interfaces available, SNMP/MODBUS/dry contacts/emergency stop EPO/USB/RS232/RS485/CAN, etc.
-Conformal Coated PCA component
-Customizable waterproof level, IP20-IP56
-Low fault rate, as low as 0.35% (0.3% -0.5%)
-Can connect to 2 independent mains (dual mains input)
-Adjustable number of battery units
