Original new HW SFP 10G ER 1310 Gigabit single mode optical module 40km 1310nm LC interface
- Category: >>>
- Supplier: Shenzhen Toptoday Network Co. Ltd.
Share on (1601059275099):
Product Overview
Description
Original new HW SFP-10G-ER-1310 Gigabit single-mode optical module 40km 1310nm LC interface
SFP-10G-ER-1310 indicator
| Project | Metric values |
|---|---|
| Basic information | |
| The module name | SFP-10G-ER-1310 |
| Part coding | 02311RLX |
| Model | SFP-10G-ER-1310 |
| encapsulation | SFP+ |
| Interface standards | Non-standard, compatible with 10Gbase-ER |
| The connector type | LC |
| Fiber type | SMF |
| Operating case temperature [°C] | 0°C~70°C |
| Transfer Rate [bit/s] | 10 Gbit/s |
| Target transmission distance [km] | Single-mode fiber: 40km |
| Send terminal light parameters | |
| Center wavelength [nm] | 1310nm |
| Maximum transmit optical power [dBm] | 4.0dBm |
| Minimum transmit optical power [dBm] | -2.0dBm |
| Minimum extinction ratio [dB] | 3.5dB |
| Receive terminal light parameters | |
| Reception sensitivity [dBm] | -20dBm |
| Overload optical power [dBm] | -7.0dBm |
Illustrate: SFP-10G-ER-1310 If it is connected with the optical module (1550nm, 10GE, 40km) of the 10Gbase-ER standard, the maximum transmission distance is only 20km due to different specifications such as wavelength and reception sensitivity. | |
