Good price U profile steel q235b q345b structural galvanized carbon steel c channel bar
- Category: >>>
- Supplier: Shandong Chengshun Metal Material Co. Ltd.
Share on (1601060441360):
Product Overview
Description
Product Name | steel U channel | ||||||
Model Number | 5#-40#abc, U40*20*4-U65*42*5.5, UPN50-UPN400, UPE80-UPE400, etc. | ||||||
Length | 6-12m or as required | ||||||
Web Height (h) | 50-400mm, 40-400mm, or as required. | ||||||
Flange Width (b) | 37-104mm, 20-115mm, or as required. | ||||||
Web Thickness (d) | 4.5-14.5mm, 4-14mm, or as required. | ||||||
Flange Thickness (t) | 7-18mm, 5.5-18mm, or as required. | ||||||
Material Grade | Q235B/Q235C/Q235D/Q235E, Q345B/Q345C/Q345D/Q345E, Q355B/Q355C/Q355D/Q355E, Q390B/Q390C/Q390D/Q390E, S235JR, S275J0, S275J2, S355J0, S355J2,S355JR, S355NL S460, SS400 A36, A572GR50, A992 Or as required. | ||||||
Tolerance | ±1% | ||||||
Supply Ability | 500 000 tons/month | ||||||
Sample | Free | ||||||
Packing | Export standard package or as required waterproof paper+plastic film+iron packing+strip bunding+wooden or steel pallet | ||||||
Loading Port | Tianjin, Qingdao, Shanghai or Guangzhou. | ||||||
Model Number | Size (mm) | Cross-sectional area | Theoretical weight | ||||
web height (h) | flange width (b) | web thickness (d) | （cm²） | （kg/m） | |||
5# | 50 | 37 | 4.5 | 6.928 | 5.438 | ||
6.3# | 63 | 40 | 4.8 | 8.451 | 6.634 | ||
6.5# | 65 | 40 | 4.3 | 6.709 | |||
8# | 80 | 43 | 5 | 10.248 | 8.045 | ||
10# | 100 | 48 | 5.3 | 12.748 | 10.007 | ||
12# | 120 | 53 | 5.5 | 12.059 | |||
12.6 | 126 | 53 | 5.5 | 15.692 | 12.319 | ||
14#a | 140 | 58 | 6 | 18.516 | 14.535 | ||
14#b | 140 | 60 | 8 | 21.316 | 16.733 | ||
16#a | 160 | 63 | 6.5 | 21.962 | 17.24 | ||
16#b | 160 | 65 | 8.5 | 25.162 | 19.752 | ||
18#a | 180 | 68 | 7 | 25.699 | 20.174 | ||
18#b | 180 | 70 | 9 | 29.299 | 23 | ||
20#a | 200 | 73 | 7 | 28.837 | 22.637 | ||
20#b | 200 | 75 | 9 | 32.837 | 25.777 | ||
22#a | 220 | 77 | 7 | 31.846 | 24.999 | ||
22#b | 220 | 79 | 9 | 36.246 | 28.453 | ||
25#a | 250 | 78 | 7 | 34.917 | 27.41 | ||
25#b | 250 | 80 | 9 | 39.917 | 31.335 | ||
25#c | 250 | 82 | 11 | 44.917 | 35.26 | ||
28#a | 280 | 82 | 7.5 | 40.034 | 31.427 | ||
28#b | 280 | 84 | 9.5 | 45.634 | 35.832 | ||
28#c | 280 | 86 | 11.5 | 51.234 | 40.219 | ||
30#a | 300 | 85 | 7.5 | 34.463 | |||
30#b | 300 | 87 | 9.5 | 39.173 | |||
30#c | 300 | 89 | 11.5 | 43.883 | |||
32#a | 320 | 88 | 8 | 48.513 | 38.083 | ||
32#b | 320 | 90 | 10 | 54.913 | 43.107 | ||
32#c | 320 | 92 | 12 | 61.313 | 48.131 | ||
36#a | 360 | 96 | 9 | 60.91 | 47.814 | ||
36#b | 360 | 98 | 11 | 68.11 | 53.466 | ||
36#c | 360 | 100 | 13 | 75.31 | 59.118 | ||
40#a | 400 | 100 | 10.5 | 75.068 | 58.928 | ||
40#b | 400 | 102 | 12.5 | 83.068 | 65.208 | ||
40#c | 400 | 104 | 14.5 | 91.068 | 71.488 | ||
Shandong Chengshun Metal Material Co., LTD We are a professional manufacturer engaged in the research, development, production, sale and service. Our main products include PPGI ,galvanized steel , steel plate , round bar, steel pipe ,Stainless steel product ,angle bar, steel pile ,H beam ,I beam, angle, Channel flat steel etc . Main market distributes in North America, South America, Africa, Southeast Asia as well as Oceania. Up to now, we have established long-term and win-win partnership with many large steel manufacturers, such as Baosteel, Laiwu Steel, Rizhao Steel, Handan Iron and Steel, Angang and Maanshan Iron and Steel. Sincerely wish to build a long and regular business with you forever.
1. Q: Are you a factory or trading company?
A: We are a Chinese manufacture of steel pipes with both factories and trading companies.
2. Q: Can I get samples before order?
A: Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings.
3. Q:what is your delivery time?
A:The time of delivery is usually around 1 month. We can send out in 3 days if it has stock.
4. Q:What is your payment terms?
A:Our usual payment term is 30% deposite, and rest against L/C. EXW, FOB, CFR, CIF, etc.
5.Q:What do your factory do regarding quality control?
A:We have gained ISO, CE,API authentication. From material to products, we inspect each process to keep good quality.
6. Q:How can you ensure what I got will be good?
A: Alibaba will act as our guarantor. If the product fails the inspection before leaving the factory, you can refuse to accept the goods.
7. Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefit ; we respect every customer as our friend and we sincerely do business and make friends with them. No matter where they come from.
Please leave your enquiry in the message box at the bottom of the product page and click SEND, online salesman will contact you at once!
