Mold preheating platform large cast aluminum heating table for laboratory
- Category: >>>
- Supplier: Jiangsu Zixuanhong Electric Heating Technology Co. Ltd.
Share on (1601060563239):
Product Overview
Description
Product Description
The heating table is widely used for sample baking, drying, and other temperature tests,
and is an essential tool for biology, genetics, medicine and health, environmental protection, biochemical laboratories, analysis rooms, teaching and research.
and is an essential tool for biology, genetics, medicine and health, environmental protection, biochemical laboratories, analysis rooms, teaching and research.
Its main characteristics:
1. The working panel is made of stainless steel, aluminum, graphite,
ceramics, and copper, which have superior corrosion resistance.
2. Fast and uniform heating, easy to operate, and safe to use.
1. The working panel is made of stainless steel, aluminum, graphite,
ceramics, and copper, which have superior corrosion resistance.
2. Fast and uniform heating, easy to operate, and safe to use.
Main Features
Condition | New |
Type | Air Heater |
Power Source | Electric |
Place of Origin | China |
Jiangsu | |
Brand Name | ZXH-JRT |
Dimension(L*W*H) | Customized |
Voltage | 220V |
Warranty | 1 Year |
Working Temperature Range | 0℃ - 400℃ |
Material | Stainless steel |
Key Selling Points | Easy to Operate |
Digital display | Room temperature -400 degrees Resolution: 1 degree |
flatness | +-0.5mm |
Real usage temperature | 350C |
Insulation thickness | 100mm |
Insulation material | Ceramic fiber |
Manufacturing Technique
Specification
Model | Size | Voltage | Power | Material | Weight | Temperature |
ZXH-LB- 100-100 | 100*100 mm | 220V | 300W | Aluminium sheet | 2KG | 400C |
ZXH-LB- 150-150 | 150*150mm | 220V | 500W | Aluminium sheet | 3KG | 400C |
ZXH-LB- 200-200 | 200*200mm | 220V | 1000W | Aluminium sheet | 5KG | 400C |
ZXH-LB- 300-300 | 300*300mm | 220V | 1500W | Aluminium sheet | 7KG | 400C |
ZXH-LB- 400-300 | 400*300mm | 220V | 1800W | Aluminium sheet | 9KG | 400C |
ZXH-LB- 500-500 | 500*500mm | 220V | 3000W | Aluminium sheet | 12KG | 400C |
ZXH-LB- 600-400 | 600*400mm | 220V | 3000W | Aluminium sheet | 12KG | 400C |
ZXH- BXG- 100-100 | 100*100mm | 220V | 300W | Stainless | 2KG | 400C |
ZXH- BXG- 150-150 | 150*150mm | 220V | 500W | Stainless | 2.5KG | 400C |
ZXH- BXG- 200-200 | 200*200mm | 220V | 1000W | Stainless | 4KG | 400C |
ZXH- BXG- 300-300 | 300*300mm | 220V | 1500W | Stainless | 5kg | 400C |
ZXH- BXG- 400-300 | 400*300mm | 220V | 1800W | Stainless | 7KG | 400C |
ZXH- BXG- 500-500 | 500*500mm | 220V | 3000W | Stainless | 10KG | 400C |
ZXH- BXG- 600-400 | 600*400mm | 220V | 3000W | Stainless | 10KG | 400C |
Installation Instructions
１．Set the temperature: Press the SET button to set the temperature.Click the SET button. The data of the lower row of digital tubes flashes (the upper row is normally measuring temperature). At this time, the instrument enters the temperature setting state. Press the△ key to set the value to increase, press the▽ key to set the value to decrease, and then click the SET button. The instrument returns to normal operation. The temperature setting is complete.
2．Correction of sensor error: Press the SET button for 3 seconds to enter the inner menu of the instrument. After selecting the parameter SC, cooperate with the△ or▽ button to correct the error.The correction range with a display resolution of 1 degree is ±50 degrees.After completion, press the SET key for 3 seconds to exit.The correction value of the instrument is 0 when it leaves the factory.
3．Start self-tuning: This product can adapt to most control systems, and can only start self-tuning if the control effect is particularly unsatisfactory.Method 1: After the meter is powered on, press the shift button for 3 seconds to start the self-tuning.Method 2: Press the SET button for 3 seconds to enter the inner menu of the instrument. After selecting the parameter At, press the△ button to adjust the lower row to 1, and then press the SET button for 3 seconds to turn on the self-tuning.When the self-tuning is in progress, the Atu indicator light flashes. The process is that the instrument-controlled heating system fluctuates twice near the set point. When the Atu indicator light is off, the self-tuning ends, and the new PID parameters are locked in the chip.
2．Correction of sensor error: Press the SET button for 3 seconds to enter the inner menu of the instrument. After selecting the parameter SC, cooperate with the△ or▽ button to correct the error.The correction range with a display resolution of 1 degree is ±50 degrees.After completion, press the SET key for 3 seconds to exit.The correction value of the instrument is 0 when it leaves the factory.
3．Start self-tuning: This product can adapt to most control systems, and can only start self-tuning if the control effect is particularly unsatisfactory.Method 1: After the meter is powered on, press the shift button for 3 seconds to start the self-tuning.Method 2: Press the SET button for 3 seconds to enter the inner menu of the instrument. After selecting the parameter At, press the△ button to adjust the lower row to 1, and then press the SET button for 3 seconds to turn on the self-tuning.When the self-tuning is in progress, the Atu indicator light flashes. The process is that the instrument-controlled heating system fluctuates twice near the set point. When the Atu indicator light is off, the self-tuning ends, and the new PID parameters are locked in the chip.
Packing & Delivery
Company Profile
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2021,sell to Western Europe(30.00%),Domestic Market(30.00%),North America(30.00%),South America(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
heating element,band heater,silicone rubber heater,cartridge heater,flange immersion heater
4. why should you buy from us not from other suppliers?
Our design, Your success!
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Jiangsu, China, start from 2021,sell to Western Europe(30.00%),Domestic Market(30.00%),North America(30.00%),South America(10.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
heating element,band heater,silicone rubber heater,cartridge heater,flange immersion heater
4. why should you buy from us not from other suppliers?
Our design, Your success!
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
