IE 2000 8TC G B IE2000 series 8 10/100 2 T/SFP LAN Base switch Industrial grade switch
- Category: >>>
- Supplier: Beijing Xuyang Entrepreneurial Network Technology Co. Limited
Share on (1601060989293):
Product Overview
Description
Product Description
IE-2000-8TC-G-B IE2000 series 8 10/100 2 T/SFP LAN Base switch Industrial grade switch
IE-2000-8TC-G-B is the IE2000 series 8 10/100, 2 T/SFP, and LAN Base switch. The IE 2000 Series are designed for low cost, low ports, and small sizes. They offer:
1. Four, eight, or 16 10/100Base-T Ethernet ports (Small Form-Factor Pluggable [SFP] downlinks on selected models); fixed configurations with a compact form factor
2. Two gigabit combo ports: SFP (100 Mbps and 1 Gbps) or RJ45 uplink
3. Dual-input DC power supply, alarm relays, DIN rail mount
4. Industrial Power over Ethernet (PoE) solution
5. Conformal coating available
6. Swappable SD flash card and mini-USB connector
7. Industrial environmental compliance and certifications
8. Industrial partner applications: Ethernet/IP and PROFINET
IE-2000-8TC-G-B Specification | |
Physical Specification | |
Total Ports | 10 |
RJ45 Ports | 8 FE |
Combo Ports | 2 GE |
Manufacturing license | LAN Base |
Power consumption | 8-port downlink models: 12.5-20 W |
Hardware | 256 MB DRAM with ECC memory IEEE 1588v2 FPGA 64 MB on-board flash memory 1GB removable SD flash memory card (optional) Mini-USB connector |
Alarm | Alarm I/O: Two alarm inputs to detect dry contact open or close; one alarm output relay |
Connectors and cabling | 10/100/1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling |
IE2000 Software Features | |
LAN Lite license | Baseline features |
Layer 2 switching | IEEE 802.1, 802.3, 802.3at, 802.3af standard (see Table 8), VTPv2, NTP, UDLD, CDP, LLDP, Unicast MAC filter, Resilient Ethernet Protocol (REP), Media Redundancy Protocol (MRP) Ring (IEC 62439-2) |
Security | SCP, SSH, SNMPv3, TACACS+, RADIUS Server/Client, MAC Address Notification, BPDU Guard, SPAN session |
Multicast | IGMPv1, v2, v3 Snooping, IGMP filtering, IGMP Querier |
Management | Fast Boot, Express Setup, Web Device Manager, CNA, Prime, LMS, MIB, SmartPort, SNMP, syslog |
Industrial Ethernet | EtherNet/IP, Profinet v2 |
LAN Base license | Additional features |
Layer 2 switching | VTPv3, EtherChannel, Voice VLAN, Flexlink |
Security | IPv4 Port-Security, DHCP Snooping, Dynamic ARP Inspection, IP Source Guard, 802.1x, Guest VLAN. MAC Authentication Bypass, 802.1x Multi-Domain Authentication, Storm Control, Trust Boundary, Access-List (ACL) |
Quality of service | IPv4 Ingress Policing, Rate-Limit, Egress Queuing/Shaping, AutoQoS, PROFINET QoS |
Management | Port-Based DHCP, Storm Control - Unicast, Multicast, Broadcast, SPAN Sessions, RSPAN, DHCP Server, Customized TCAM/SDM Size Configuration, Embedded Event Manager (EEM) |
Industrial Ethernet | IEEE 1588 PTPv2 |
IPv4 routing | IPv4 static routing |
IPv6 routing | IPv6 host support, HTTP over IPv6, SNMP over IPv6 |
Enhanced LAN Base | Additional features |
Industrial management | Layer 2 switching with 1:1 static Network Address Translation (NAT) |
IP Lite license | Additional features |
IPv4 routing | RIP, OSPF, EIGRP, VRF Lite, PIM for L3 multicast routing including sparse (SM) and dense (DM) mode. |
IPv6 Routing | IPv6 Static routing, OSPFv3 |
Security | FIPS 140-2 |
Embedded Event Manager | EEM feature enabled with IP Lite license |
DNA Essentials | Additional features |
DNA Center | Discovery, topology, inventory, software image management |
Visibility | DNA assurance, Device 360 |
Day-zero network bring-up automation | Network Plug-and-Play application |
Our Services
1. Condition: All the items are 100 % Original.
.
2. The Fastest Delivery: We ensure you that we can fast ship the equipment upon your confirmation.
3. The Best Service: certified sales engineers are here to offer presales suggestion and solve the problems of installation.
4. The Highest Quality: All equipment is fully tested and authenticated byCCIE engineers and provided 1 year warranty.
