12.8V LiFePO4 18650 li ion rechargeable battery 36Ah lithium battery pack lead acid replacement solar battery
- Category: >>>
- Supplier: Hunan Fengri New Energy Technology Co. Ltd.
Share on (1601061626650):
Product Overview
Description
Products Description
Lead Acid Replacement | ||||
Model | LBR12-36 | |||
Nominal capacity | 36Ah | |||
Min. capacity | 35Ah | |||
Nominal energy | 460.8Wh | |||
Combination structure of battery | 32700-4S6P | |||
Nominal voltage | 12.8V | |||
Discharge cut-off voltage | 10.8V | |||
Standard charge voltage | 14.6±0.2V | |||
Float charge voltage | 13.8V | |||
Standard charge current | 6A | |||
Recommended charge current | ≤30A | |||
Allowed Max. continuous charge current | 30A | |||
Standard discharge current | 10A | |||
Recommended discharge current | ≤40A | |||
Allowed Max. continuous discharge current | 40A | |||
Peak current | 100A,10Sec | |||
Internal Impedance | ≤60mΩ | |||
Weight | Approx.3.3kg | |||
Dimensions | 198*166*170mm | |||
Case material | ABS | |||
Terminals | M8 | |||
Ex-factory capacity | Approx.50% SOC | |||
Service life | ≥2000 cycles | |||
Operation temperature range | Discharge | -20℃~60℃ | ||
Charge | 0℃~45℃ | |||
Storage conditions | ≤1Month | -20～+60℃、5～75%RH | ||
≤6Month | -10～+45℃、5～75%RH | |||
Recommend environment | 15～+35℃、5～75%RH | |||
Professional product customization service! | ||||
Compared with lead-acid batteries, lithium batteries have the following advantages:
1. Environmental protection: lead-free, in line with new energy environmental protection requirements;
2. Light weight: only 30% of the weight of lead-acid batteries;
3. Long life: more than 2000 cycle life, life span of up to 10 years;
4. High power: can provide twice the power output of lead-acid batteries;
5. Temperature range: Wider temperature use environment, low temperature discharge is better than lead-acid battery.
6. Flexibility: Modular design, 4 series and multiple parallels can be realized.
3. Long life: more than 2000 cycle life, life span of up to 10 years;
4. High power: can provide twice the power output of lead-acid batteries;
5. Temperature range: Wider temperature use environment, low temperature discharge is better than lead-acid battery.
6. Flexibility: Modular design, 4 series and multiple parallels can be realized.
Company Profile
Certifications
Packing & Shipping
FAQ
Q: If we could accept OEM & ODM service?
A: We could accept customized, such as the brand, Logo, Container color, etc. The premise is to reach a certain Quantity.Q:How many days for lead time normally?
A:Normally 3-7 days for samples order. and 1-4 weeks for mass order normally depend on order quantity or complexity.Q:Whether we support to make a sample order?
A:Yes, we can efficiently make the sample or customized item for your reference and test before mass order.Q: About the certificates & Other services
A: We have a professional export sales team with full experience, and you just need to confirm the batteries you need and also advise us of the certificates you need and the docs for customs clearance.We Recommend
