Monocular Shake Head Camera HD Night Vision Smart Wireless Phone Remote Control Network Home Surveillance Camera

Product Overview

Description

Monocular Shake Head Camera HD Night Vision Smart Wireless Phone Remote Control Network Home Surveillance Camera





Model: WS-YP24

Dimension: (L*W*H): 73mm*73mm*107mm

micro usb 5v/1.5a Power supply

Image Sensor: 1/3′′ COMS  3MP pixels

Lens: 2.8MM @ F2.0,105°

Resolution Ratio: 2304*1296

Network setup: WIFI

Wireless Standard: 2.4GHz WiFi(IEEE 802.11b/g/n)

Night vision light source: white light/infrared LED

Video Storage: Cloud Storage,local SD card(Max.128GB)

Alarm notice: Alarm push by mobile APP,white light flashing and alarm sound



Product Parameters

3 million shaking head module,single light (real pixel 2 million)

H.264/H.265 video encoding, supports dual streams

Main stream: 2304*1296@15fps; Subcode stream:800x448@15fps

Supports 3D noise reduction , supports digital wide dynamic range, AAC, G711

supports horizontal and vertical flipping

2.4G, 802.11b/g/n WIFI

humanoid tracking; humanoid picture frame; motion detection; alarm information push; supports mobile phone and client remote Monitoring

Support N1 protocol

Power supply: DC 5 v / 1A, power consumption: ≤3W

Lightning protection: tvs 4000v lightning protection, surge prevention and wave prevention; 7 * 24 hours 65℃ high temperature test stability and reliable (including the whole machine test)



Product features

3MP high-definition pixels, clear and delicate image;

WIFI connection, scan the QR code to easily connect the camera and the network, easy to operate;

With a hot spot connection, no network can also view and video playback;

Support cloud storage and local TF card video storage, to ensure the safe storage of video data;

Supports two-way voice intercom with MIC and speaker;

Intelligent mobile tracking, found that people break into the area will automatically track;

Area mobile detection, push the alarm information;

Cloud platform supports customized any Angle, adapted to different machine shell, 10 preset position;

Support the remote monitoring of mobile phone, PC client, and view the live scene anytime and anywhere;

Intelligent humanoid detection, filter false positives, and accurately protect your safety
