120L/Min Diaphragm Vacuum Pump oil free vacuum pump

Share on (1601062895256):


Price:$450.00 - $466.00

Quantity:


Product Overview

Description


                                  GM-2 120L/Min Diaphragm Vacuum Pump









Product Description








Features:





• The product could work with out any medium and does not produce pollution. The gas exchange room is placed with filtering material,

to ensure that the air is clean.

• New material and new technology are adopted in production. It is convenient to move, and work smoothly, thus ensuring the ideal

vacuum degree and higher air velocity.

• Using frictionless membrane body movement, does not produce heat, no friction consumption. Imported rubber diaphragmhas corrosion

resistance and long servicelife.

• Automatic cooling exhaust system is designed in the body, ensures continuous operation 24 hours a day .

• The pressure adjustable design can satisfy a certain range of vacuum and gas velocity.

• Bearing imported classic bearing, smooth operation, low noise, high efficiency.

• The parts in contact with the gas of anticorrosive pump is with NYLON surface treatment, which have complete ability of

resistance to chemical corrosion .

• Special motor is ODM provided by the export of professional motor manufacturer and has got the European CE certification. It has the

reasonabl e rotation design, equipped with a power overheat protector, when the pump body temperature reached 130 degrees,

it will automatically power off, to protect the motor from being damaged in the long running work .

• Small volume and light weight, easy to move, save space, convenient repair and maintenance.










Application:





1. Vacuum filtration


2. Vacuum distillation


3. Vacuum adsorption


4. Solvent filtration


5. Solid phase extraction


6. Degassing


7. For compression and air conversion gas








Technical parameters:




























































Speed of evacuation 120 L /Min
Extreme pressure vacuum  ≥ 0.08MPa  200mbar
Voltage rating220V / 1 10V; 50Hz / 60Hz
Motor power  300w
Inlet φ 9mm
Out let φ 9mm
Temperature of working env i ronment  7 - 40ºC
Funct ion Vacuum & Pressure
Pump head 2
Temp of the body (ºC ) <55
Dimens ions ( L×W×H )390 × 150 × 250mm
Noi selevel≤ 60 DB
Weight 20Kg










Our Services


Warranty Service





From the date of acceptance, we can provide 12 months quality guarantee, all the maintenance costs and accessories parts costs are free within the date of quality guarantee (spare and accessories parts costs from instrument faults by human factors will be charged proper costs).





After the date of quality guarantee, we will in charge of maintain instrument, and charge proper costs according to actual maintenance costs.











Company Information


Our motto: First-Rate Service, First-Rate Quality.








 Gongyi City Yuxiang Instrument Co.,Ltd is located in Zhengzhou city, Henan Province, China, it was established in year 2002, has passed more than 20 years. It is a technological innovation-based enterprise provided with integration of research,   development, manufacture and marketing; it has 7,400 square meter factory; In year 2019, we expanded a larger sister company---Zhengzhou Huachen Instrument Co., Ltd, which has 11,000 square meter factory, so as to provide more professional products and services to our customers.


Our factory-1.jpgOur factory-2.jpg














Certifications


certification





Trade Shows


.jpg





Packaging & Shipping







FAQ


1. Are you the factory?





Yes, we’re.


Established in 2002, we manufacture rotary evaporator,  jacketed glass reactor, chiller etc.





2. What is the delivery time?





Generally speaking, the delivery time is 7-10 days for regular products. For the customized instrument, about 10~20 days is needed





3. What’s the warranty period? How do you provide this?





One year (12 months).


We have very strict inspection and testing to make sure the instruments which you received are high-quality and reliable.


If there’s any problem, we’ll provide you the on line solution in 12 hours. If the problem is caused by accessory, we’ll provide you the spare parts for free. If the problem is caused by the instrument quality, and cannot be repaired, we’ll ship you the new one.
