Stainless steel 2PCS female thread gas oil water ball valve
- Category: >>>
- Supplier: Wenzhou Kinding Machinery Co. Ltd.
Share on (1601070566714):
Product Overview
Description
Products Description
Application
Sanitary type ball valves can be applied to material conveying. Application range of this kind of valve includes food, beverage processing and chemical industy etc. Full run-through valve chamber will not result in any fluid resistance. therefore this valve can be used to treat fluid which is viscous or contains particulate matter.
Product Name | Sanitary Economy Ball Valve |
Body Material | SS304 / SS316 |
Surface treatment | Ra<0.8μm |
Seat Material | Silicone, EPDM, FKM.PTFE |
Connection method | Clamped, Threaded, Welded, flanged |
Size | 1/2"-6".DN15 to DN150.other size can be customized |
Standard | DIN/SMS/3A/ISO/IDF/RJT/BPE/DANSK |
Operating Type | Manual / Pneumatic /Electric |
Application | Food, beverage, dairy, chemical |
● Serviceable Valve - Can be taken apart via threads, Female NPT Ports
● Handle: Heavy duty handle with blue vinyl insulation
● Body & Ball Type:304 Stainless Steel. Temp Range: -60 F to 450 F
● Nominal Working Pressure:1000 WOG: Max 1000 psi for Water, Oil, Gas
● Fluid temp range: -20°f to 410°f
● The valve is fitted with PTFE seals for maximizing corrosion resistance and lifespan of the ball valve
● This multi-purpose manual lever ball valve has excellent corrosion resistance and is fit for many applications
● Handle: Heavy duty handle with blue vinyl insulation
● Body & Ball Type:304 Stainless Steel. Temp Range: -60 F to 450 F
● Nominal Working Pressure:1000 WOG: Max 1000 psi for Water, Oil, Gas
● Fluid temp range: -20°f to 410°f
● The valve is fitted with PTFE seals for maximizing corrosion resistance and lifespan of the ball valve
● This multi-purpose manual lever ball valve has excellent corrosion resistance and is fit for many applications
Company Profile
Wenzhou Kinding Machinery co.,Ltd is located at a beautiful and traffic-convenient Longwan district of Wenzhou city, ,mainly engaged in developing,manufacturing,installation and techanical service in food, beverage, biology, pharmacy, chemical industry fields. We have advantage in producing high quality stainless steel equipment, such as fruit pulping machine, sanitary centrifugal pump, rotary lobe pump, high shear pump, etc. The enterprise has passed ISO9001:2008, our products are made of SUS304, SUS316 and SUS316L, conforming to sanitary standard stated in GMP specification.
Certifications
Best stainless
Design material according to customer ' s requirement, test all the raw material to confirm SS304, SS304L, SS316, SS316L.
Package and Shipping
FAQ
Q1: Are you trading company or manufacturer?
A: We are factory.
Q2: How long is your delivery time?
A: Generally it is 3-7 days if the goods are in stock. or it is 10-15 days if the goods are not in stock, it is according to quantity.
Q3: Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight for the fittings.
Q4: What is your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
