Factory Price Growatt on Grid Inverter Max 50~80ktl3 LV on Grid 3 Phase 400V Inverter
- Category: >>>
- Supplier: Anhui GP New Energy Co. Ltd.
Share on (1601072628120):
Product Overview
Description
Products Description
Details Images
Product Parameters
Datasheet | ||||||||
Model Name | MAX 50KTL3 LV | MAX 60KTL3 LV | MAX 70KTL3 LV | MAX 80KTL3 LV | ||||
Input AC | ||||||||
Recommended max. PV power | 75KW | 90kW | 105kW | 120kW | ||||
Max. input voltage | 1100V | |||||||
Rated voltage | 585V/600V | |||||||
Start-up voltage | 250V | |||||||
MPPT voltage range | 200V-1000V | |||||||
Max. input current | 26A | |||||||
Max. short circuit current | 32A | |||||||
MPPT number/Max. input strings number | 6 | 6 | 7 | 7 | ||||
Output AC | ||||||||
Rated output power | 50kW | 60kW | 70kW | 80kW | ||||
Max. apparent output power | 55.5kVA | 66.6kVA | 77.7kVA | 88.8kVA | ||||
Rated grid voltage | 220V/380V, 230V/400V (340-440V) | |||||||
Rated grid frequency | 50/60Hz | |||||||
Max. output current | 80.5A | 96.6A | 112.7A | 128.8A | ||||
Power Factor | 0.8leading 0.8lagging | |||||||
THDi | <3% | |||||||
Efficiency | ||||||||
Max. efficiency | 98.7% | |||||||
EU efficiency | 98.5% | |||||||
Protection | ||||||||
DC reverse-polarity protection | Yes | |||||||
Short circuit protection | Yes | |||||||
Output over current protection | Yes | |||||||
Surge protection | Yes | |||||||
Grid monitoring | Yes | |||||||
Anti-islanding protection | Yes | |||||||
Temperature protection | Yes | |||||||
Integrated AFCI (DC arc-fault circuit protection) | Yes | |||||||
Integrated DC switch | Optional | |||||||
General Data | ||||||||
Dimensions (W*H*D) | 860/600/300mm | |||||||
Weight | 82KG | 82KG | 86KG | 86KG | ||||
Topology | Transformerless | |||||||
Self consumption | <1W (night) | |||||||
Operating ambient temperature range | -25 ~ +60°C | |||||||
Relative humidity | 0-100% | |||||||
Ingress protection | IP65 | |||||||
Cooling concept | Natural convection | |||||||
Max. operation altitude | 4000m | |||||||
Safety/EMC standard | IEC 62109-1/-2, IEC 62116, EN 61000-6-1/-2/-3/-4 | |||||||
Features | ||||||||
DC connection | H4/MC4(Optional) | |||||||
AC connection | Cable gland+OT terminal | |||||||
Display | OLED+LED/WIFI+APP | |||||||
Interfaces | RS485/USB/WiFi/ RF/GPRS | |||||||
Warranty | 10 years | |||||||
Packing & Delivery
Company Profile
ANHUI GP NEW ENERGY CO., LTD
We, Anhui GP New Energy Co., Ltd (Great Pack) focus on LiFePO4, Li-polymer, Li-ion rechargeable batteries, solar energy batteries, are the leading Lifepo4 battery supplier in China, who committed to the R&D, design, and innovation of lithium batteries to supply Green & Clean energy to our daily modern lives!
Our team has over 8 years of experience in the lithium battery field, and supplies One Step Power Solution suggestions to help you to save time & capital and achieve advanced technologies and excellent OEM/ODM service.
Quality is life, Great Pack is committed to supplying high-quality batteries and the best service to our clients all over the
world. Our battery has passed CE, UN38.3, RoHS, and MSDS certificates. We are committed to becoming a leading solution provider to go global in the Solar lithium battery industry.
Our team has over 8 years of experience in the lithium battery field, and supplies One Step Power Solution suggestions to help you to save time & capital and achieve advanced technologies and excellent OEM/ODM service.
Quality is life, Great Pack is committed to supplying high-quality batteries and the best service to our clients all over the
world. Our battery has passed CE, UN38.3, RoHS, and MSDS certificates. We are committed to becoming a leading solution provider to go global in the Solar lithium battery industry.
Exhibition
Certifications
FAQ
What does a solar inverter do?
It's a device that converts direct current (DC) electricity, which is what a solar panel generates, to alternating current (AC)
electricity, which the electrical grid uses.
electricity, which the electrical grid uses.
What is the difference between a string solar inverter and a hybrid inverter?
Hybrid inverters generate power exactly the same way as common string solar inverters. The difference is that it has built-in battery connections to enable energy storage for later use. This battery backup ability enables most hybrid systems to also operate as a backup power supply during a blackout.
Can you go off-grid with hybrid inverter?
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
What are the basic parameters of inverter?
There are 3 parameters that will define the output of power inverter, and they are the frequency, the voltage, and power capacity.
