Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries
Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries
Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries
Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries
Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries
Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries
Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries

Namkoo Gel Batteries 12V 150ah Baterias Solares 150 Ah 150 Amp ABS 110V 150ah Battery 12 V 150 Ah Deep Cycle Batteries

Share on (1601073546271):


Price:$136.00 - $148.00

Quantity:


Product Overview

Description



Product Description











Product Information

baterias solares 150ahbaterias solares 150ah









Description


By combining the service life reliability of a flooded battery with the performance energy density of a valve-regulated battery, CBB created a true long service life VRLA battery the 2V gel range. This range offers 15-20 years design life with very good cycling capability, and it is highly suited to telecom, UPS, renewable energy system, power stations and similar applications. It owns much better thermal stability and longer cyclic life.








Product Parameters


Working theory


The grid-tied solar system is mainly composed of photovoltaic modules,grid inverter and other accessories. It generates the DC power from solar panel and convert DC power into AC for the loads by inverter. This system can be set to use the solar power initially, but when solar power is not sufficient for the loads, the national grid will be the back up power for the loads consumption. Of course, if the power is surplus after offering the loads consumption, the surplus power will be delivered back to grid automatically


Application Range


1.There is a national grid supply





















































































Model



6-GFM-150Ah




6-GFM(G)-150Ah



Cells Per Unit



6



Voltage Per Unit



12



Capacity



150Ah@10hr-rate to 1.80V per cell @25°C



Weight



43 Kg




47 Kg



Internal Resistance



Approx. 3.5 m




Approx. 4 m



Terminal



F8



Max. Discharge Current



2250A (5 sec)



Design Life



6~8 years




10~15 years



Maximum Charging Current



37.5A




Reference Capacity



C10 150.0AH
C3 115AH

C1 82.8AH




C10 150.0AH

C3 108.7AH
C1 82.4AH



Float Charging Voltage



13.6 V~13.8 V @ 25°C

Temperature Compensation: -20mV/°C/Cell



Cycle Use Voltage



14.4 V~14.9 V @ 25°C

Temperature Compensation: -30mV/°C/Cell



Operating Temperature Range



Discharge: -15°C~50°C

Charge: 0°C~40°C

Storage: -15°C~40°C




Discharge: -20°C~60°C

Charge: 0°C~50°C

Storage: -20°C~60°C



Normal Operating Temperature Range



25°C±5°C



Self Discharge



Less than 3% at 25°C per month



Container Material



A.B.S. UL94-HB, UL94-V0 Optional









Company Information








baterias solares 150ah


As a leader in solar power station, NAMKOO POWER is committed to building high-quality solar power station and setting up industry benchmarks, providing users quality services and safely Tailor-made engineering solutions as well as money for a long time. We provide systematic bank financing plan and full range of insurance for each customer to protect their income. NAMKOO POWER adheres to the goal of building a quality power station. Through global channels, technological means and continuous research and development innovation capabilities, NAMKOO POWER strives to make greater contributions to the development of global clean energy, the improvement of people's quality of life, and the construction of blue sky.
