Original Emerson Micro Motion ELITE CMF200H Coriolis Meter, 2 Inch (DN50), Nickel Alloy C22
- Category: >>>
- Supplier: JACKWELL. INC
Share on (1601076534340):
Product Overview
Description
Product Description
Specification
item | value |
Warranty | 1 year |
Customized support | OEM, ODM |
Place of Origin | United State |
Brand Name | Micro Motion- ELITE Coriolis |
Model Number | Micro Motion- ELITE CMF200H Coriolis |
Type | Variable Area Petrolum Flowmeters, Variable Area Oil Flowmeters |
A Nickel Alloy C22 ELITE peak performance Coriolis flow meter designed to deliver accurate, repeatable flow measurement in the most challenging applications.
Mass flow accuracy (Liquid)±0.10% of rate (standard)±0.05% of rate (optional)
Mass flow repeatability (Liquid)±0.05% of rate (standard)±0.025% of rate (optional)
Volume flow accuracy (Liquid)±0.10% of rate (standard)±0.05% of rate (optional)
Volume flow repeatability (Liquid)±0.05% of rate (standard)±0.025% of rate (optional)
Mass flow accuracy (Gas)±0.35% of rate
Mass flow repeatability (Gas)±0.20% of rate
Density accuracy (Liquid)±0.0005 g/cm3 (±0.5 kg/m3) (standard)±0.0002 g/cm3 (±0.2 kg/m3) (optional)
Density repeatability (Liquid)±0.0002 g/cm3 (±0.2 kg/m3) (standard)±0.0001 g/cm3 (±0.1 kg/m3) (optional)
Temperature accuracy±1 °C ±0.5% of reading
Sensor maximum working pressure2,755 psig (190 barg)
Meter approvals, calibrations, and certifications
•UL
•CSA
•IECEx
•NEPSI
•ATEX
•Ingress Protection
•EMC effects
Specifications
Mass flow accuracy (Liquid)±0.10% of rate (standard)±0.05% of rate (optional)
Mass flow repeatability (Liquid)±0.05% of rate (standard)±0.025% of rate (optional)
Volume flow accuracy (Liquid)±0.10% of rate (standard)±0.05% of rate (optional)
Volume flow repeatability (Liquid)±0.05% of rate (standard)±0.025% of rate (optional)
Mass flow accuracy (Gas)±0.35% of rate
Mass flow repeatability (Gas)±0.20% of rate
Density accuracy (Liquid)±0.0005 g/cm3 (±0.5 kg/m3) (standard)±0.0002 g/cm3 (±0.2 kg/m3) (optional)
Density repeatability (Liquid)±0.0002 g/cm3 (±0.2 kg/m3) (standard)±0.0001 g/cm3 (±0.1 kg/m3) (optional)
Temperature accuracy±1 °C ±0.5% of reading
Sensor maximum working pressure2,755 psig (190 barg)
Meter approvals, calibrations, and certifications
•UL
•CSA
•IECEx
•NEPSI
•ATEX
•Ingress Protection
•EMC effects
Features
* Get unparalleled measurement sensitivity and stability from this uniquely designed meter
* Gain real-time and in-process measurement integrity assurance with Smart Meter Verification
* Realize unmatched flow and density measurement performance in your most challenging liquid, gas and slurry applications
* Achieve superb measurement confidence with the highest immunity to fluid, process and environmental effects
* Improve scalability with a broad array of application coverage including hygienic, cryogenic and high-pressure
* Implement the widest process-measurement range – -400°F to 662°F (-240°C to 350°C) and up to 6,000 psig (414 barg)
* Widest range of meter approvals and certifications, including; CSA, ATEX, NEPSI, IECEx, Ingress Protection 66/67, SIL2 and
SIL3, marine, and custody transfer approvals
* Choose from models available in 316L Stainless Steel, C-22 nickel alloy and super-duplex materials
* Interact with our 3D model to learn more about our ELITE Coriolis Flow and Density Meters
* Get unparalleled measurement sensitivity and stability from this uniquely designed meter
* Gain real-time and in-process measurement integrity assurance with Smart Meter Verification
* Realize unmatched flow and density measurement performance in your most challenging liquid, gas and slurry applications
* Achieve superb measurement confidence with the highest immunity to fluid, process and environmental effects
* Improve scalability with a broad array of application coverage including hygienic, cryogenic and high-pressure
* Implement the widest process-measurement range – -400°F to 662°F (-240°C to 350°C) and up to 6,000 psig (414 barg)
* Widest range of meter approvals and certifications, including; CSA, ATEX, NEPSI, IECEx, Ingress Protection 66/67, SIL2 and
SIL3, marine, and custody transfer approvals
* Choose from models available in 316L Stainless Steel, C-22 nickel alloy and super-duplex materials
* Interact with our 3D model to learn more about our ELITE Coriolis Flow and Density Meters
