Bus Model | ECITY L10 | |||
General Parameters | ||||
Dimensions(mm) | 10600×2500×3270 | |||
Wheelbase(mm) | 5800 | |||
GVW. (kg) | 17000 | |||
Front overhang(mm) | 2320 | |||
Rear overhang(mm) | 2480 | |||
Front track(mm) | 2100 | |||
Rear track(mm) | 1870 | |||
Approach/departure angle(°) | 8/8 | |||
Passenger capacity (sitting and standing, without driver) | 76 | |||
Chassis Paramters | ||||
Motor | Model No | TQSL100A-6/380 | ||
Rated power/speed/torque | 100kW/800rpm/1200N-m | |||
Peakpower/speed/torque | 210kW/3000rpm/2700Nm | |||
Motor Control System | Model No | EC311-b67V1-164A | ||
Battery Pack | Battery total capacity(kWh) | 270.7 | ||
Battery total capacity(Ah) | 519 | |||
Battery total voltage(M | 521.64 | |||
Battery cells(V/Ah) | CATL3.22/173 | |||
Suspension | Front suspension | Air suspension, WABCO ECAS | ||
Rear suspension | Air suspension, WABCO ECAS | |||
Air Conditioner Parameters | ||||
Roof-mounted integral cooling/heating air conditioner | Pure electric air conditioner for heating and cooling, with thermal management | |||
