3.7v 7.4v 11.1v 12v 150mah 280mah 600mah 5000mah 20000mah Rechargeable Li Ion Cell Lipo Battery Lithium Polymer Battery

Item

Rating

Note

Capacity

Typical

1000mAh

Discharge:0.2CmA

cut off Voltage:3.0V for cell

Minimum

1000mAh

Nominal Voltage

Average  3.7V

Discharge:0.2CmA

cut off Voltage:3.0V for cell

AC Impedance Resistance

≤230mΩ

Discharge Cut-off Voltage

3.00V

Charge Current

0.2C

Standard Charge

Charge Voltage

4.2V

Max. Charge Voltage

4.23V

Charge Time

Approx 1.5h

Charge: 1.0CmA

Max. Charge Current

1000mA

1.0CmA

Max. Discharge Current

1000mA

Weight

Approx 18g

Operating Temperature

Charge

0~+45°C

Discharge

-20~+60°C

Storage Temperature

less than 1 month

-20~+45°C

Recommended storage

temperature: 20°C,at the

shipment state

less than 3 months

-20~+35°C
