Product Overview
Description
Electrical Characteristics | STC : AM1.5 1000W/m2 25℃ Test uncertainty for Pmax:±3% | ||||||||
Module Type | LR5-72HTH-565M | LR5-72HTH-570M | LR5-72HTH-575M | LR5-72HTH-580M | LR5-72HTH-585M | ||||
Testing Condition | STC | STC | STC | STC | STC | ||||
Maximum Power (Pmax/W) | 420 | 425 | 430 | 435 | 440 | ||||
Open Circuit Voltage (Voc/V) | 38.73 | 38.93 | 39.13 | 39.33 | 39.53 | ||||
Short Circuit Current (Isc/A) | 14.00 | 14.07 | 14.15 | 14.22 | 14.30 | ||||
Voltage at Maximum Power (Vmp/V) | 32.44 | 32.64 | 32.84 | 33.04 | 33.24 | ||||
Current at Maximum Power (Imp/A) | 12.95 | 13.03 | 13.10 | 13.17 | 13.24 | ||||
Module Efficiency(%) | 21.5 | 21.8 | 22.0 | 22.3 | 22.5 | ||||
Mechanical Parameters | ||
Cell Orientation | 108 (6×18) | |
Junction Box | IP68 | |
Output Cable | 4mm2, ±1400mm length can be customized | |
Glass | Single glass, 3.2mm coated tempered glass | |
Frame | Anodized aluminum alloy frame | |
Weight | 20.8kg | |
Dimension | 1722×1134×30mm | |
Packaging | 36pcs per pallet / 216pcs per 20’GP / 936pcs per 40’HC | |
Operating Parameters | ||
Operational Temperature | -40℃ ~ +85℃ | |
Power Output Tolerance | 0 ~ 3% | |
Voc and Isc Tolerance | ±3% | |
Maximum System Voltage | DC1500V (IEC/UL) | |
Maximum Series Fuse Rating | 25A | |
Nominal Operating Cell Temperature | 45±2℃ | |
Protection Class | Class II | |
Fire Rating | UL type 1 or 2 IEC Class C | |
Mechanical Loading | ||
Front Side Maximum Static Loading | 5400Pa | |
Rear Side Maximum Static Loading | 2400Pa | |
Hailstone Test | 25mm Hailstone at the speed of 23m/s | |
Temperature Ratings（STC） | ||
Temperature Coefficient of Isc | +0.050%/℃ | |
Temperature Coefficient of Voc | -0.230%/℃ | |
Temperature Coefficient of Pmax | -0.290%/℃ | |
