SANY Rotary Foundation Drill Rig SR215 C10 SR235S Bore Pile Machine Rotary Drilling Rig
- Category: >>>
- Supplier: Sany Group Co. Ltd.Sany Ltd.
Share on (1601095824528):
Product Overview
Description
Products Description
Features
Efficient and Flexible
· They are widely used in civil engineering in small dia. and deep borehole construction, high main hoist lifting up and down speed, tall verticality of the finished boreholes, and high working efficiency in civil construction.
· They are widely used in civil engineering in small dia. and deep borehole construction, high main hoist lifting up and down speed, tall verticality of the finished boreholes, and high working efficiency in civil construction.
Special Chassis
· Telescopic large widening chassis designed for rotary drilling rig, roller type large diameter slewing bearing to guarantee the high stability in deep borehole construction.
· Telescopic large widening chassis designed for rotary drilling rig, roller type large diameter slewing bearing to guarantee the high stability in deep borehole construction.
Economical and Energy-saving
· Imported large-displacement EFI engine with solid power, adopts power optimization control technology, adjusts power distribution in real time, fast response speed, higher fuel efficiency, and more energy-saving.
· Imported large-displacement EFI engine with solid power, adopts power optimization control technology, adjusts power distribution in real time, fast response speed, higher fuel efficiency, and more energy-saving.
High Reliability
· The mast adopts a box structure with solid resistance to torsion and fatigue; the sixth-generation Kelly bar adopts upgraded material and strengthened block ring; the overall strength increased by 25% with high drilling ability in the strongly weathered rock layer.
· The mast adopts a box structure with solid resistance to torsion and fatigue; the sixth-generation Kelly bar adopts upgraded material and strengthened block ring; the overall strength increased by 25% with high drilling ability in the strongly weathered rock layer.
Intelligent Upgrade
· 10-inch HD touch screen, fast response, and more convenient operation.
· 10-inch HD touch screen, fast response, and more convenient operation.
Specs & Compare
Models | Max. Pile Diameter | Max. Pile Depth | Operating Weight |
SR65-C10 | 1100 mm | 27/20 m | 23 T |
SR125-C10 | 1300 mm | 45/36 m | 37 T |
SR155-C10 | 1500 mm | 55/44 m | 48 T |
SR185-C10 | 1800 mm | 59/47 m | 63 T |
SR215-C10 | 1800 mm | 64/51 m | 65 T |
SR235S | 2000 mm | 68/52 m | 81 T |
SR285R-C10 | 2300 mm | 94/61 m | 100 T |
SR305S | 2500 mm | 100/65 m | 105 T |
