Main technical parameter: | ||
Plate size | 600*700mm | |
Printing size | 400 * 400mm | |
Max. Paper width | 420mm | |
Max. printing width | 410mm | |
Max. Unwind diameter | 600mm | |
Printing speed | 0-8000imp/hour | |
Registration accuracy | +/- 0.1mm | |
Main motor power | 3.5KW | |
Machine size | 4600L*1600W*1650H | |
Machine weight | 3000kg | |
Electrical and parts brand: | ||||
Item name | Brand | Origin | ||
Motion controller | Googo | Taiwan | ||
Printing ervo motor | Fuji | Japan | ||
Pulling servo motor | Fuji | Japan | ||
Servo reducer | Kmiab | Japan | ||
Registration sensor | Panasonics | Japan | ||
Inverer | Schneider | France | ||
Touch screen | Pro-face | Taiwan | ||
