Steel Wire Clip Clamp Stainless Steel Double Wire Spring Hose Clamp Clip Hydraulic Wire Radiator Hose Clamps:
1) Size: 11-14mm to all
2) Materials: Galvanized Steel, 201/304 Stainless Steel
3) Wire Diameter: 1.8mm, 2.0mm, 2.2mm, 2.5mm
4) Screw: M5x30mm, M6x40/50/60/70mm
| Size(mm) | Wire Dia. (mm) | Screw(mm) | Pcs/Bag | Pcs/Carton | Measure(cm) |
| 11-14 | 1.5 | M5x30 | 50 | 1000 | 32x27x14 |
| 13-16 | 1.5 | M5x30 | 50 | 1000 | 32x27x14 |
| 15-18 | 1.5 | M5x30 | 50 | 1000 | 32x27x14 |
| 17-20 | 1.8 | M5x30 | 50 | 1000 | 32x27x14 |
| 19-22 | 1.8 | M5x30 | 50 | 1000 | 38x27x17 |
| 20-24 | 1.8 | M5x30 | 50 | 1000 | 38x27x17 |
| 22-26 | 1.8 | M5x30 | 50 | 1000 | 38x27x17 |
| 24-28 | 1.8 | M5x30 | 50 | 1000 | 38x27x17 |
| 26-30 | 2.2 | M6x40 | 50 | 500 | 38x27x19 |
| 28-32 | 2.2 | M6x40 | 50 | 500 | 38x27x19 |
| 31-35 | 2.2 | M6x40 | 50 | 500 | 38x27x24 |
| 34-38 | 2.2 | M6x40 | 50 | 500 | 38x27x24 |
| 35-40 | 2.2 | M6x40 | 50 | 500 | 38x27x24 |
| 37-42 | 2.2 | M6x40 | 50 | 500 | 38x27x24 |
| 40-45 | 2.2 | M6x40 | 50 | 500 | 38x27x24 |
| 43-48 | 2.2 | M6x50 | 50 | 500 | 38x27x34 |
| 45-50 | 2.2 | M6x50 | 25 | 500 | 38x27x34 |
| 47-52 | 2.2 | M6x50 | 25 | 500 | 38x27x34 |
| 50-55 | 2.2 | M6x50 | 25 | 500 | 38x27x34 |
| 53-58 | 2.2 | M6x50 | 25 | 250 | 38x27x19 |
| 55-60 | 2.2 | M6x60 | 25 | 250 | 38x27x19 |
| 54-62 | 2.2 | M6x60 | 25 | 250 | 38x27x24 |
| 60-65 | 2.2 | M6x60 | 25 | 250 | 38x27x24 |
| 63-68 | 2.2 | M6x60 | 25 | 250 | 38x27x29 |
| 65-70 | 2.2 | M6x70 | 25 | 250 | 38x27x29 |
| 70-75 | 2.2 | M6x70 | 10 | 250 | 38x27x34 |
| 75-80 | 2.2 | M6x70 | 10 | 250 | 38x27x34 |
Hot Products
Contact Us
Company Information
FAQ
1. Question: What does your company doing?
Answers: Many factories main doing assembly by purchasing parts, we manufacture all the parts by ourselves except standard screw. The quality of our products can be guaranteed.
2. Question: Can you put our company's logo on the band of the hose clamps?
Answers:Yes. we can put your logo if you can provide us with copyright and letter of authority. OEM order is welcome.
3. Question: Can you provide sample?
Answers: Yes, we can provide samples which cost is under USD 30.00 and weight less than 0.5 kgs.
