Hot Seller Plastic Creasing Matrix Paperboard Creasing Matrix
- Category: >>>
- Supplier: Gakei Youpin (guangzhou) Industry And Trade Co. Ltd.
Share on (1601110292693):
Product Overview
Description
Product Paramenters
Product Name | High quality PIKE creasing matrix | ||||||
Brand | PIKE | ||||||
Material | PVC，Paper fiber，Glass fiber | ||||||
Size | Various specifications as you need | ||||||
Package | 50pcs/Box | ||||||
MOQ | 1 Box | ||||||
Shipping Way | DHL,FEDEX,UPS ,TNT ,by air by sea and send to your agent | ||||||
Service | Stock also can make your need sizes | ||||||
Payment | Chinese account，T/T, Western Union, Trade Assurance | ||||||
Delivery time | About 3-7 working Days | ||||||
Products Description
Product advantages
1. World’s most advanced creasing matrix made from plastic suitable for short-run job with average punching times from 20,000-50,0000
2. Accurate locator – ensures perfect registration
3. Low profile chamfer – board flows freely over the matrix; board marking is reduced
4. Finger lift adhesive tape – backing paper easily and quickly removed
5. New and strong adhesive removes cleanly from the plate after use, will not move about during die cutting jobs
6. Special sizes available to suit all board types, off-centers and multi-crease for close creasing rule
7. It is extremely durable and accurate and provides benefits in time and cost.
8. Competitive price with high quality
2. Accurate locator – ensures perfect registration
3. Low profile chamfer – board flows freely over the matrix; board marking is reduced
4. Finger lift adhesive tape – backing paper easily and quickly removed
5. New and strong adhesive removes cleanly from the plate after use, will not move about during die cutting jobs
6. Special sizes available to suit all board types, off-centers and multi-crease for close creasing rule
7. It is extremely durable and accurate and provides benefits in time and cost.
8. Competitive price with high quality
Specification Selection：
*For instance:the thickness of the cardboard:0.52mm;the thickness of creasing rules:0.71mm,according to calculation formula:A=0.52≈0.5(mm);B=0.52*1.5+0.71=1.49≈1.5(mm),so we should choose the size of 0.5*1.5
*Method to choose creasing matrix size for corrugated paper.Size table(subjct to 23.8mm die-cutting rules).
1 Measure the length of the creasing rule.
2 Mark the measurement and cut the matrix.
3 Mount the cut piece onto the creasing rule with locator.
4 Remove all the back tapes.
5 Transfer the matrix and locator onto the counter plate.
6 Remove all the locators.
7 Mitre the sharp angle.
2 Mark the measurement and cut the matrix.
3 Mount the cut piece onto the creasing rule with locator.
4 Remove all the back tapes.
5 Transfer the matrix and locator onto the counter plate.
6 Remove all the locators.
7 Mitre the sharp angle.
Company Profile
We are GAKEI Youpin (Guangzhou) Industry & Trade Co., Ltd. We are mainly engaged in printing consumables, and we have 13 years of experience.
Such as rubber rollers, creasing matrix, die-cutting machines, bending machine, Die cutting rule , punching machines, spring punch, drill bit , creasing matrix cutting machines, ceramic anilox cleaner, sawing machines, ejection rubber, doctor blade, ink end seals, ceramic anilox rollers, die cutting rule puller machine, nick grinder machine, tesa tape, die cutting molds,Waste stripper stripping machine and etc.
