Used Agilent 8594A HP8594A 3GHz Spectrum Analyzer 9K 2.9GHz network analyzer
- Category: >>>
- Supplier: Shenzhen Huazexun Electronic Technology Co. Ltd.
Share on (1601110773113):
Product Overview
Description
Product Description
Specification
item | value |
Place of Origin | America |
Brand Name | Agilent |
Model Number | 8594A |
Product details
Product model: 8590A series
Brief introduction
Brand: HP Agilent
Frequency range:
HP 8590A: 9kHz~1.5GHz; Minimum interval 1kHz(option 130)
HP 8591A: 9kHz~1.8GHz; Minimum interval 1kHz(option 130)
HP 8594A: 9kHz~2.9GHz; Minimum interval 1kHz(option 130)
HP 8595A: 9kHz~6.5GHz; Minimum interval 1kHz(option 130)
HP 8596A: 9kHz~ 12.8GHz; Minimum interval is [1×N] kHz (option 130)
HP 8593A: 9kHz~ 19.25GHz; Minimum interval is [1×N] kHz(option 130)
A detailed introduction of portable spectrum analyzer 8590A
* Easy to use, scalable harmonic spectrum analyzer
* Available in a wide range of prices and performance
* Measurements such as FFT, TOI, ACP can be made at the touch of a button
* With extended memory and trace storage
* Narrow resolution bandwidth is available
* Customized special test software is available
HP8590A series spectrum analyzer
The HP8590A series spectrum analyzer has a variety of performance, functions, and its price is determined to adapt to the affordability of users. Users can choose from inexpensive, basic performance analyzers up to high performance analyzers, and no matter which analyzer they choose, they will feel that the HP8590A series spectrum analyzer is easy to use and highly reliable. The scalable nature of these instruments makes it easy to configure them to meet the increasing measurement requirements of users.
With application test software, the analyzer can be adapted for specific test work, such as cable television, electromagnetic compatibility (EMC), radio frequency communications, noise factor and scalar network analysis measurements. Users can also add a variety of printers, plotters and other accessories.
One spectrum analyzer is suitable for many applications
Users can change the test functions of this range of spectrum analyzers to suit specific measurement requirements. The memory card reader can be loaded with measurement specific software. Complex measurement procedures are reduced to a single keystroke input. The HP8590A series special option plug-in box allows the addition of circuit card options to complete additional functions. The optional built-in tracking generator provides a synchronous scan signal source for excitation-response measurement. Operating any of the HP8590A series spectrum analyzers requires minimal training.
Easy to use
There are many features that make the control of the measurement and the analysis of the measurement results much easier. This series of spectrum analyzers has built-in automatic calibration to ensure measurement consistency. The panoramic sweep can quickly re-determine the position of the signal without repeated scanning. The internal memory can store more than 50 traces, while a memory card reader can store more traces on RAM. The time and date are indicated in a standard manner. With the choice of HP-IB/ parallel or RS-232/ parallel interfaces, the results can be output directly to the printer or plotter. This option supports HP printers and certain specified Epson printers.
PC software for HP8590A series
The newly developed HP BenchLink Spectrum Analyzer PC software provides a convenient communication link between a PC and the HP8590A series spectrum analyzer. By taking full advantage of the Windows interface, users can easily transfer screen images or trace data through the HP-IB or RS-232 interface, thus simplifying the process of obtaining, analyzing and recording measurement results in a PC environment.
HP8591A, 8593A, 8594A, 8595A and 8596A spectrum analyzers
These easy-harmonic spectrum analyzers provide a powerful combination of measurement capabilities for RF, microwave and digital applications. Five models offer frequency coverage options starting at 9kHz and extending to 26.5GHz.
Performance indicators include low phase noise of -105 DBC at 30kHz frequency offset and frequency synthesis accuracy of 2.1kHz at 1GHz. With an optional precision frequency reference, the frequency synthesis accuracy can be increased to 210Hz. The second and third order dynamic ranges are 77 and 90dB respectively. When using option 130, the calibration amplitude range is +30~-130dBm, but the calibration screen display is 70dB. With optional circuit cards, narrow resolution bandwidths of 30, 100, 200EMI and 30Hz are available. Circuit cards can be installed on these analyzers at any time.
Standard characteristic
The window function divides the display screen into two horizontal areas, allowing the user to zoom in on key parts of the measurement trace, or display test data and trace simultaneously. It has a number of standard single-button measurement features, including frequency scale table, FFT(Fast Fourier Transform), NdB bandwidth, third-order interception, amplitude modulation percentage, and adjacent channel power. The built-in memory card reader allows 32k, 128k, 256k and 512k memory cards to be fed into measurement applications, user's own dedicated programs and measurement data.
A wide variety of options
An increasing number of circuit card options provide more measurement capabilities. The circuit card is easy to fit into the built-in plug-in slot, and most circuit cards can be updated.
Brief introduction
Brand: HP Agilent
Frequency range:
HP 8590A: 9kHz~1.5GHz; Minimum interval 1kHz(option 130)
HP 8591A: 9kHz~1.8GHz; Minimum interval 1kHz(option 130)
HP 8594A: 9kHz~2.9GHz; Minimum interval 1kHz(option 130)
HP 8595A: 9kHz~6.5GHz; Minimum interval 1kHz(option 130)
HP 8596A: 9kHz~ 12.8GHz; Minimum interval is [1×N] kHz (option 130)
HP 8593A: 9kHz~ 19.25GHz; Minimum interval is [1×N] kHz(option 130)
A detailed introduction of portable spectrum analyzer 8590A
* Easy to use, scalable harmonic spectrum analyzer
* Available in a wide range of prices and performance
* Measurements such as FFT, TOI, ACP can be made at the touch of a button
* With extended memory and trace storage
* Narrow resolution bandwidth is available
* Customized special test software is available
HP8590A series spectrum analyzer
The HP8590A series spectrum analyzer has a variety of performance, functions, and its price is determined to adapt to the affordability of users. Users can choose from inexpensive, basic performance analyzers up to high performance analyzers, and no matter which analyzer they choose, they will feel that the HP8590A series spectrum analyzer is easy to use and highly reliable. The scalable nature of these instruments makes it easy to configure them to meet the increasing measurement requirements of users.
With application test software, the analyzer can be adapted for specific test work, such as cable television, electromagnetic compatibility (EMC), radio frequency communications, noise factor and scalar network analysis measurements. Users can also add a variety of printers, plotters and other accessories.
One spectrum analyzer is suitable for many applications
Users can change the test functions of this range of spectrum analyzers to suit specific measurement requirements. The memory card reader can be loaded with measurement specific software. Complex measurement procedures are reduced to a single keystroke input. The HP8590A series special option plug-in box allows the addition of circuit card options to complete additional functions. The optional built-in tracking generator provides a synchronous scan signal source for excitation-response measurement. Operating any of the HP8590A series spectrum analyzers requires minimal training.
Easy to use
There are many features that make the control of the measurement and the analysis of the measurement results much easier. This series of spectrum analyzers has built-in automatic calibration to ensure measurement consistency. The panoramic sweep can quickly re-determine the position of the signal without repeated scanning. The internal memory can store more than 50 traces, while a memory card reader can store more traces on RAM. The time and date are indicated in a standard manner. With the choice of HP-IB/ parallel or RS-232/ parallel interfaces, the results can be output directly to the printer or plotter. This option supports HP printers and certain specified Epson printers.
PC software for HP8590A series
The newly developed HP BenchLink Spectrum Analyzer PC software provides a convenient communication link between a PC and the HP8590A series spectrum analyzer. By taking full advantage of the Windows interface, users can easily transfer screen images or trace data through the HP-IB or RS-232 interface, thus simplifying the process of obtaining, analyzing and recording measurement results in a PC environment.
HP8591A, 8593A, 8594A, 8595A and 8596A spectrum analyzers
These easy-harmonic spectrum analyzers provide a powerful combination of measurement capabilities for RF, microwave and digital applications. Five models offer frequency coverage options starting at 9kHz and extending to 26.5GHz.
Performance indicators include low phase noise of -105 DBC at 30kHz frequency offset and frequency synthesis accuracy of 2.1kHz at 1GHz. With an optional precision frequency reference, the frequency synthesis accuracy can be increased to 210Hz. The second and third order dynamic ranges are 77 and 90dB respectively. When using option 130, the calibration amplitude range is +30~-130dBm, but the calibration screen display is 70dB. With optional circuit cards, narrow resolution bandwidths of 30, 100, 200EMI and 30Hz are available. Circuit cards can be installed on these analyzers at any time.
Standard characteristic
The window function divides the display screen into two horizontal areas, allowing the user to zoom in on key parts of the measurement trace, or display test data and trace simultaneously. It has a number of standard single-button measurement features, including frequency scale table, FFT(Fast Fourier Transform), NdB bandwidth, third-order interception, amplitude modulation percentage, and adjacent channel power. The built-in memory card reader allows 32k, 128k, 256k and 512k memory cards to be fed into measurement applications, user's own dedicated programs and measurement data.
A wide variety of options
An increasing number of circuit card options provide more measurement capabilities. The circuit card is easy to fit into the built-in plug-in slot, and most circuit cards can be updated.
